PAGE 18 — LD6 RIDE-ON POWER TROWEL • OPERATION MANUAL — REV. #0 (02/10/20)
SPECIFICATIONS
Table 2. LD6 Trowel Specifications
Operating Weight 850 lb. (386 kg)
Shipping Weight 960 lb. (435 kg)
Maximum Rotor Speed 140 rpm
Blades per Rotor 4
Path Width 75 in. (1,905 mm)
Hydraulic Oil Capacity 0.45 gal. (1.70 liters)
Hydraulic Oil Type Parker DuraClean ISO 46
Table 3. Vanguard Engine Specifications
Model Briggs & Stratton Vanguard 3864
Type Small block, V-twin, horizontal shaft,
air-cooled, OHV, gasoline engine
Number of Cylinders 2
Displacement 38.3 CID (627 cm³)
Compression Ratio 8.4:1
Bore × Stroke 2.97 × 2.76 in. (75 × 70 mm)
Maximum Output 23 hp (17 kW @ 3,600 rpm)
Oil Capacity with Filter 48 oz. (1.4 liters)
Oil Type High-quality detergent oil classified
“For service SF, SG, SH, SJ” or higher.
Spark Plug Type Resistor
Spark Plug Gap 0.030 in. (0.76 mm)
Fuel Type Minimum 87 octane unleaded gasoline
Fuel Capacity 4 gallons (15 liters)
NOTES:
1. Sound pressure and power levels are “A” weighted measures per ISO 226:2003 (ANSI S1.4-1981). They are measured using operating
conditions of the machine which generate the most repeatable but highest values of the sound levels. Under normal circumstances, the sound
level will vary depending on the condition of the material being worked upon.
2. The vibration level indicated is the vector sum of the RMS (root mean square) values of amplitudes on each axis, standardized to an 8-hour
exposure period, and obtained using operating conditions of the machine that generate the most repeatable but highest values in accordance
with the applicable standards for the machine.
3. Per EU Directive 2002/44/EC, the daily exposure action value for whole body vibration is 0.5 m/s
2
SA(8). The daily exposure limit value is
1.15 m/s
2
SA(8).
Table 4. LD6 Noise and Vibration Emissions
Guaranteed ISO 11201:2010 Based Sound Pressure Level at Operator Station in dB(A) TBD
Guaranteed ISO 3744:2010 Based Sound Power Level in dB(A) TBD
Whole Body Vibration per ISO 2631-1:1997 in m/s
2
SA(8) 0.05
