WTB-16PD TRACK-DRIVE POWER BUGGY • OPERATION MANUAL — REV. #0 (08/31/20) — PAGE 19
1. Tub or Bucket — Used for the transportation of
material. Tub holds approximately 16 cubic feet
(0.59 cubic yards) of water.
2. Left Track Steering Lever — Controls left side of track
buggy. Reference Table 6 for directional positioning.
Allows the buggy to move in either a forward or reverse
direction.
3. Brake Lamp — When lit, indicates that the parking
brake is set (ON).
4. Oil Alert Lamp — When lit, indicates low engine oil.
This condition will cause the engine to shut down.
5. Right Track Steering Lever — Controls right side
of track buggy. Reference Table 6 for directional
positioning. Allows the buggy to move in either a
forward or reverse direction.
6. Handlebar — Grip this handlebar with both hands
when driving the buggy.
7. Brake Switch Knob — This switch sets and releases
the parking brake.
8. Emergency Stop Button — In the event of an
emergency, press this button to shut down the engine.
9. Fuel Valve Lever — When placed in the ON position
fuel will flow. OFF position stops fuel flow. ALWAYS
place this lever in the ON position when starting the
engine.
10. Charcoal Canister — Charcoal-activated system
that absorbs or traps fuel vapors. Basic component of
evaporative emissions control systems.
11. Documentation Canister — Store and maintain
Operation, Parts and Engine manuals in this container
at all times.
12. Relay/Fuse Panel — Contains one relay (parking
brake solenoid) and two fuses. The 5-amp fuse provides
protection for the parking brake relay. The 15-amp fuse
provides protection for the heat exchanger.
13. Parking Brake Solenoid — When activated, engages
the parking brake.
14. Engine — This machine uses an electric start, 20 hp,
Honda GX690 air-cooled gasoline engine.
15. Hydraulic Oil Access Port — There are five of these
ports on the machine. Remove the access cover to
clean out the hydraulic oil reservoir.
16. Engine Oil Drain Plug — Remove plug to drain engine
crankcase oil.
17. Tub Pivot Pedal — Use this pedal to pivot the tub.
Press down on the pedal to rotate tub to the left. Lift
up on the pedal to rotate tub to the right.
18. Dump Pedal — Use this pedal to place the tub in the
dump (vertical) position. Press the pedal a second
time to return the tub to the travel (horizontal) position.
19. Rubber Track — Inspect track daily for wear and
tear. DO NOT use the machine if the rubber track is
damaged.
20. Rubber Track Adjustment Bolt — Use this bolt to
adjust tension of the rubber track. Check tension daily.
21. Tie-Down Hook — When transporting of the buggy is
required, attach a strap to these tie-down points (4).
22. Towing Hook — Use this hook to tow the buggy if it
gets stuck on the job site. The machine must be placed
in free-wheel mode before towing, otherwise damage
to drive motors will occur. DO NOT tow on public roads
BUGGY COMPONENTS
