MULTISPAN DSM-14N - Mechanical Dimensions; Unit Dimensions and Panel Cutout

www.multispanindia.com
Page-9
DSM-14N
MODEL
DIMENSIONS
A
96mm
96mm
92mm
92mm 3mm
52mm
56mm
B
C D E F G
F
D
G
E
A
B
B
RightSideView
TopView
Mechanical Dimension
Prepare the panel cutout with proper dimensions as show below.
