IMC01 Frequently Asked Questions
Version 1.05
Figure 2- 9 The Direction of Wheel Rotation to Take the Jammed Bill
2) Turn off the auto counting feature.
3) Insert one banknote into the gap between the rollers to check if the banknote can be inserted smoothly, as
shown in the following.
Figure 2- 10 The Banknote Feeding Gap
Figure 2- 11 Using a banknote to check the gap between the rollers
4) If the banknote is hard to insert, that means the feeding gap is too small. Rotate the screw clockwise until
the banknote can be inserted smoothly. If the feeding gap is so large that two or more banknotes can be
inserted to the feeding gap, please rotate the screw counterclockwise until the gap can just allow one
banknote at a time.
5) Use the banknote to check the other sides of the gap between rollers, to make sure the banknote can be
inserted into both sides of the feeding gap smoothly.
The 2 feeding
gaps between
rollers
