Muncie ADVANTAGE + - SPREADER ISSUES; SYSTEM IS OVERHEATING; CONTROLLER ERROR MESSAGES

29
ADVANTAGE PLUS SYSTEM TROUBLESHOOTING
SPREADER ISSUES
ISSUE POTENTIAL PROBLEMS
Spinner Does Not Operate Check the Controllers Speed Settings
Check the Plumbing - Are we deadheading the function
Check the quick disconnects
If the function operates when switch motors, could have faulty motor
Check the Spreader Relief Valve for contamination
Check CV9 - is LS signal being relayed back to boost pressure valve
Check CV10 - is the LS signal being relayed back to boost pressure valve
Auger / Conveyor Does Not Operate
Check the controllers speed settings
Check the Plumbing - Are we deadheading the function
Check the quick Disconnects
Swapping supply to spinner, could have faulty motor
Check the Spreader Relief Valve for contamination
Check CV8 - is LS signal being relayed back to boost pressure valve
Check CV10 - is LS signal being relayed back to boost pressure valve
SYSTEM IS OVERHEATING
ISSUE POTENTIAL PROBLEMS
System is Getting Hot 1. Check the standby pressure - Contamination in LS Drain
2. Check pressure with motors engaged - Bad Quick Disconnect
3. Verify that we do not have excess pump ow
4. Verify that the low oil / cold oil sensor isn’t plugged into the wrong input
CONTROLLER ERROR MESSAGES
ISSUE
Air/Road Temp Sensor Not Functioning 1. Verify that a sensor is installed and wired correctly
2. Make sure that the system is congured for this sensor (must be factory congured)
3. Check the Power and Ground Connections of the sensor
4. Verify that all of the pins are in the correct locations and seated correctly in their housing
5. Verify that the lens cover was removed after installation
Air / Road Temp Sensors are Incorrect
1. Try Calibrating the Sensor to the Controller
2. Verify the Air / Road Temp Sensor is mounted in an appropriate location and not reading
temperatures from the exhaust.
3. Contact Muncie for Lens replacement
PSI Not Displayed on Controller 1. Verify that the appropriate connector is plugged into the transducer receptacle
2. Verify that the pin of the connector are seated properly.
Incorrect PSI Shown on Controller
1. Replace the Pressure Transducer
