Dehumidifier M KD-series
3.8 Replacingthe memorybattery
If the hour counters cannot be read when disconnected from mains, it is probably due to flat memory
battery. Replacement procedure:
WARNING!
Alwaysdisconnectfromthemainsbeforechangingbattery
Action
1 Slacken the screws on both side of the
control panel, and carefully lift the
panel up using the top edge
2 Cut the cable tie holding the battery. Replace the battery, using a new cable tie max. 2.5 mm wide.
Use Alkaline AAA batteries
only Illustration of PCB with battery included in the wiring diagram
on pag
e 22.
190TEN-1071-C1304 Operation 14
