Dehumidifier M KD-series
1.5 Transportofthedehumidifier
NOTE! Observelocalworkingenvironmentrulesas regardsheavylifting
Twopeopleoracranecanmovethedehumidifier. See the instructions below
2 people Hoist/crane
Lift as shown below Lifting u sing a cargo strap
The wheels are positioned such that the machine can be pulled upstairs without damage to the cabinet or
stairs.
1.6 Stacking
Max. two dehumidifiers should be stacked on t op of each other. Press the handle of the lower dehumidifier
to the bottom before stacking. T he handle then fits a notch on the upper dehumidifier.
1.7 Operationprinciple
The following describes the air flow through the dehumidifier :
1. A fan draws in humid air through a filter to the dehumidifier
2. The air is cooled down and humidity/water drops are led down to the water tank
3. The air is reheated by the operation of the dehumidifier (approx. increase in temperature is +5 °C)
3 Introduction 190TEN-1071-C1304
