DehumidierML180-MLT350
ML
Munter s
420
1
2
3
5
5
4
C
B
D
A
Figure4.4Ductsrequiredforinstallation
A.Processairinlet1.Dryairdamper
B.Dryairoutlet
2.Externallterbox(option)
C.Reactivationairinlet
3.Ducttransition
D.Wetairoutlet4.Reactivationairdamper
5.Outlet/inletduct(wirenetting)
190TGB-1034-L1604Installation11
