NOTE Allowing the screen to return to the main screen by waiting in this manner erases any
changes made to the parameters.
•
When a value is being modified with the arrow keys (either ▲ or ▼), the changes occur at
a rate of two changes per second. After holding down an arrow key for three seconds,
the changes occur at a rate of 10 changes per second.
•
If the system displays one of the Hot Keys and no alarms arise, the screen is refreshed
every second. If the system displays a Hot Key screen and alarms arise, both the Hot Key
screen and the alarm are displayed alternately every three seconds. If more than one
alarm is activated, the Hot Key screen displays the different alarms alternately.
3.7 LEDs
The following illustrations detail the SMART-8C/3MD LEDs
1 - 3
