- 10 -
1
Machine Setup
1 Machine Setup
This chapter explains the initial setup for the machine, including the names of the machine
components, how to unpack and install the machine, how to turn on/off the machine, and how to load
paper into tray 1.
●● Names of Components
This section shows the names of the components of the machine and operator panel.
Machine
The following shows the names of the machine
components.
2 1
11
10
9
8
7
6
5
4 3
12
No. Name
1 Top cover
2 Power switch
3 Tray 1
4 Multipurpose (MP) tray
5 Top cover open button
6 Operator panel
7 Auto document feeder (ADF) cover
8 Document tray
9 Scanner unit
10 Document glass cover
11 Air vents
12 USB port
13
No. Name
13 Document glass
17
15
14
16
No. Name
14 Fuser unit
15 Starter toner cartridge
16 Image drum
17 LED head
