Muratec MFX-3091 Quick Start Guide

- 12 -
Names of Components
1
Machine Setup
Operator Panel
The following shows the names of the components of the operator panel.
Reference
● For the details on the functions of each component, refer to the User’s Manual (Basic) > “1. Setup” > “Operator Panel”.
12
22
20
13
1519 14 17 3 4 5 18
21109876111612
No. Name
1 Display screen
2 Main function keys
<COPY> key
<SCAN> key
<PRINT> key
<FAX/HOOK> key
3 <START (MONO)> key
4 <START (COLOR)> key
5 <STOP> key
6 <STATUS> key
7 <SETTING> key
8 <REDIAL/?HELP> key
9 <RESET/LOG OUT> key
10 Ten-key pad
11 <UP> key
12 <DOWN> key
13 <LEFT> key
14 <RIGHT> key
15 <OK> key
16 <BACK> key
17 <CLEAR> key
18 <POWER SAVE> key
19 <DATA IN MEMORY> indicator
20 One-Touch key pad
21 <JOB MACRO> key
22 Qwerty keyboard
