Gauge Display
The Gauge Display screen consists of several predefined layouts that contain combinations of
analog gauges, curved bar (half-moon) gauges, straight bar gauges, or digital (text) readouts.
These screens are displayed upon startup.
You can scroll through the various gauge screens by pressing the Next and Previous buttons.
This can be repeated until all screens have been viewed. The currently displayed screen will
stay active until another button is pressed.
Gauge Display Popup
Pressing the Popup button on any of the Gauge Display screens will provide additional virtual
buttons, as shown below.
These virtual buttons provide quick navigation and access to the following features:
• Screen Names
• GPS Display
• Day/Night
• Home
