8 Replacing the cutter
(1) Replacement time
Replace the cutter when the following situation occurs:
When the media is not cut smoothly
When the cut surface is feathered, etc.
(2) Replacing steps
Step 1: If the printer is powered ON, make sure that printing or other operations are not in
progress.
Step 2: Display the CR Maintenance menu
Press the [Menu] key
“Menu1: Setup>” is displayed.
The operation panel shifts to the Setup menu display.
Press [>].
“Set1: User Type” is displayed
Press [+] or [–] to select “Set20: CR Maintenance”.
Press [Enter].
“CR Mainte.: Start” is displayed
The display enters the CR Maintenance menu.
Step 3: Press [Enter].
Maintenance starts.
The print head moves to the left of the printer (cutter replacement position).
“CR Maintenance: End” is displayed
Step 4: Open the maintenance cover at the left side of the printer.
Note
Replace the cutter in a short time.
Leaving the print head at the cutter replacement position for a long time may
result in clogging of the print head. Please limit to 15 minutes.
