MUTOH ValueJet 1604 User Manual (English)

Questions and Answers:

W
Wesley HarrisAug 19, 2025
What to do if my MUTOH ValueJet 1604 displays '[KCMY] No Cartridge'?
- M
  Michael HarringtonAug 19, 2025
  If the message appears, refer to action in check item No. 2. Remove all cartridges and lightly push the switch of ink NOT sensor assembly (K, C, M, Y) with something with a flat tip such as a ballpoint pen to check that the display of "[KCYM] INK NOT" changes. Reconnect the following connectors: MAIN board J43 and HEATER JUNCTION board connectors J5(K), J6(C), J7(M), and J8(Y). If the ink color displayed as "Ink End" changes after replacing the connector, the ink sensor assembly is damaged and should be replaced. If the ink color displayed as "Ink End" does not change after replacing the connector, the Main board assembly may be damaged and should be replaced.
S
Samantha SmithAug 21, 2025
How to resolve 'Media skew error' on a MUTOH ValueJet 1604?
- M
  Michele NashAug 21, 2025
  If this error is caused by user's inappropriate media setting, instruct correct media setting procedure. Check the connection of the following MAIN board assembly connectors: Suction fan 1 cable J25, Suction fan 2 cable J26, Suction fan 3 cable J28, and Suction fan 4 cable J29. Replace the suction fan assembly and the cable of the suction fan that does not operate normally. Remount it at the specified position. Apply grease (G501) to the pressure cam and make adjustment.
A
Amanda JacksonAug 25, 2025
How do I fix a MUTOH Printer when it says 'Set media'?
- W
  Walter Oconnor DDSAug 25, 2025
  To fix this, correctly connect the front cover R sensor assembly cable to the MAIN board assembly connector J38, and the front cover L sensor assembly cable to the MAIN board assembly connector J40. Lubricate the pressure cam. Adjust the lever sensor assembly position. Clean the sensor face using a swab. Correctly connect the lever sensor assembly cable to the MAIN board assembly connector J30. If problems persist, replace the panel unit assembly or the panel cable.
T
Thomas BryantAug 26, 2025
What to do if my MUTOH ValueJet 1604 shows 'Check Life [Head]'?
- D
  Daniel HoldenAug 27, 2025
  Replace the head as necessary and clear the counter after replacement.
H
hmartinezAug 28, 2025
What to do if my MUTOH Printer displays 'Check Life [Pump]'?
- L
  Linda FloresAug 28, 2025
  Replace the pump as necessary and clear the counter after replacement.
S
Susan PierceAug 30, 2025
What does 'Transfer failed Data format error' mean on MUTOH ValueJet 1604 and how to fix it?
- D
  David HartAug 30, 2025
  After confirming the data format, install the firmware again.
R
Randy WardSep 1, 2025
What does 'Transfer failed Aborted by the HOST' mean on MUTOH ValueJet 1604 Printer and how to fix it?
- J
  Joshua BaileySep 1, 2025
  Transfer the firmware again.
J
Jacqueline ClineSep 3, 2025
What does 'Transfer failed Data timeout' mean on MUTOH ValueJet 1604 Printer and how to fix it?
- M
  macdonaldmarthaSep 3, 2025
  After resolving the underlying issue causing the timeout, transfer the firmware again.
C
Charles WilliamsSep 6, 2025
What does 'Check Life [CR Motor]' mean on MUTOH ValueJet 1604 and how to fix it?
- D
  Dustin SpencerSep 6, 2025
  Replace the CR motor as necessary and clear the counter after replacement.
J
jeffrey63Sep 8, 2025
What does 'Transfer failed Check-sum error' mean on MUTOH ValueJet 1604 Printer?
- S
  Stephanie AndersonSep 8, 2025
  First, transfer the firmware again. If the error message is still displayed, check if the transferred firmware is an appropriate file.
