VJ-1604　 Maintenance Manual 7 Adjustment
7-15 Rev.-05
7.3.4 Receiving Parameters
This section describes the procedures for recording backup parameters to the PC from the existing main board
assembly. To download backup parameters, follow the steps below.
The extension of the parameter file is ".prm".
1. Click [Parameter Receive].
2. Click [OK] in the "Parameter Receive check"
window. Receive will start.
* Clicking [Cancel] will return to the main
window.
3. During receive of parameters, the
"Communication dialog" window will open.
* If during transfer, it is possible to stop the
transfer by clicking [Cancel].
4. Click [OK] in the "Receive completed" window.
To Next Page
