8 Maintenance VJ-1604 Maintenance Manual
Rev.-05 8-6
(2) Tools for Adjustment
8.5 Lubrication/Bonding
This section covers the lubrication/bonding information.
After disassembling/assembling this plotter, always perform necessary lubrication/bonding according to
"Table 8-6 Lubricant List" p.8-7.
Only use specified lubricants and greases. The use of unauthorized lubricants and greases
may damage the components and shorten the plotter life.
11 E ring holder (E-5) Generic product Name: JIS E-5
Manufacturer: Iwata Denko Co., Ltd
12 Penlight Generic product
13 C ring pliers Generic product For replacing take-up flange assemblies
Table 8-5 Tools for Adjustment
No. Name Part number Remarks
1 Personal computer Generic product Printer port mounted
2 Crossover cable Generic product For installing firmware
3 Tension gauge Generic product Max. 4,080gf (40N) for measurement
Manufacturer: Ohba Keiki Seisakusho Co.,
Ltd.
4 Tension gauge Generic product Max. 204gf (2N) for measurement
Manufacturer: Ohba Keiki Seisakusho Co.,
Ltd.
5 Straight scale (100 mm) Generic product -
6 MF-3G Exclusive use media For P_EDGE sensor, for print accuracy
adjustment
7 PG height check tool (64) JD-42796 -
Table 8-4 Tools for Part Replacement(Continued)
No. Name Part number Remarks
To Next Page
