VJ-1604 Maintenance Manual 7 Adjustment
7-7 Rev.-05
7.3 Working with Dedicated Network Software
In this product, download and installation of parameters, installation, firmware installation, and time settings
are performed through the network using dedicated software.
This section explains work procedures for when the "MUTOH Maintenance Engineer Assistant" is used.
When using other MUTOH network software, refer to the instruction manuals for the software.
Never provide "MUTOH Maintenance Engineer Assistant" to users because the software
enables upload of printer internal parameters to PCs.
In case of MAIN board replacement, work in the following order.
1. Setting up working environment: "7.3.3 Required Environment" p.7-10
2. Receiving parameters: "7.3.4 Receiving Parameters" p.7-15
3. Replacing MAIN board: "4.4.7 Replacing MAIN Board" p.4-49
4. DIP switch settings: "(1) DIP Switch Settings on the Main Board" p.7-16
5. Transferring firmware to plotter: "(2) Firmware Transfer" p.7-18
6. Confirming completion of installation to plotter: "(3) Confirming Completion of Installation to
Plotter" p.7-20
7. Sending parameters: "7.3.6 Sending Parameters" p.7-22
When only performing firmware version upgrade, the steps of (2), (3), (4), and (7) are not required.
