8 Maintenance VJ-1604　 Maintenance Manual
Rev.-05 8-10
8.6 Transportation of Plotter
This section describes how to transport the plotter.
Before transporting the plotter, you must package it in the same manner as it was delivered using protective
materials and packaging materials so that the plotter will not be subject to excessive impact and vibrations
during the transportation.
Follow the steps below to package the plotter.
(1) Task Before Transportation
1. Start the Self-Diagnosis Mode.
"5.2.2 Starting Up" p.5-4
2. Start the Head Cleaning Menu 2.
"5.7.8 HeadWash Menu" p.5-43
3. Discharge ink of all heads.
4. Remove all ink cartridges.
5. Install the cleaning jigs.
6. Fill shipping liquid.
7. Remove the cleaning jigs.
8. Turn the plotter power off.
9. Remove all cables including the power cable.
10. Treat the waste fluid.
11. Fit the plotter with protective materials.
12. Package the plotter.
Operation manual
(2) Task After Transportation
1. Unpack, assemble, and install the plotter.
2. Make the plotter ready for operation.
To Next Page
