4 Parts Replacement VJ-1604　 Maintenance Manual
Rev.-05 4-94
6. Remove the CR drive pulley.
7. Remove the CR speed reduction belt.
8. Replace the CR drive pulley assembly.
• The parts accompanied when removing the CR drive pulley are collectively called CR drive pulley
assembly.
• When replacing the CR speed reduction belt, reuse the CR drive pulley assembly that is currently
used.
9. To reassemble the unit, reverse the removal procedure.
10. Adjust the CR speed reduction belt tension.
"7.7 CR Speed Reduction Belt Tension Adjustment" p.7-32
11. Adjust the steel belt tension.
"7.4 Steel Belt Tension Adjustment" p.7-26
4.7.4 Replacing T Fence
1. Open the maintenance cover R.
2. Open the maintenance cover L.
3. Remove the side top cover R.
"4.2.6 Removing Side Top Cover R" p.4-12
4. Remove the side top cover L.
"4.2.7 Removing Side Top Cover L" p.4-14
5. Open the front cover.
6. Move the carriage to the left side (opposite side of the origin)
"4.8.1 Releasing Head Lock" p.4-106
7. Detach the T fence spring from the T fence spring hook in the left side of the Y rail (opposite side of the
origin).
To Next Page
