5 Self-Diagnosis Mode VJ-1604  Maintenance Manual
Rev.-05 5-62
5.12 Servo Setting
In this menu, you can change the servo settings.
* Because this is a menu for evaluating problems of the unit (noise, vibration), and improving the image
(measures for vertical unevenness) normally, do not change these parameters.
Table 5-17 Servo Setting Item
Items Contents
240 cps CW Servo setting at CR CW direction, 240 cps
240 cps CCW Servo setting at CR CCW direction, 240 cps
320 cps CW Servo setting at CR CW direction, 320 cps
320cps CCW Servo setting at CR CCW direction, 320 cps
Table 5-18 Servo Adjustment Item
Items Contents
Proportional gain Sets proportional gain
Integral gain Sets integral gain
Low-pass filter Sets low-pass filter
PWM scale Sets PWM scale
ω CSets ω C
