4 Parts Replacement VJ-1604　 Maintenance Manual
Rev.-05 4-64
15. Follow the steps in "7.6 PF Encoder Assembly Position Adjustment" p.7-30 for adjustment.
4.6.2 Replacing PF Motor Assembly
Do not touch the motor right after starting-up the plotter. Otherwise, you may be burned.
1. Initialize the PF motor assembly counter.
"5.11.1 Parameter Initialization Menu" p.5-52
2. Open the maintenance cover L.
3. Remove the side maintenance cover L.
"4.2.5 Removing Side Maintenance Cover L" p.4-12
4. Remove the rear side cover.
"4.2.8 Removing Rear Side Cover" p.4-15
5. Detach the PF speed reduction belt.
"4.6.1 Replacing PF Speed Reduction Belt" p.4-60
To Next Page
