VJ-1604 Maintenance Manual 8 Maintenance
8-3 Rev.-05
8.2 Periodical Services
This section describes the periodical services required for this printer.
The periodical services ensures stable plotting quality of the printer.
Perform periodical inspections according to Table 8-2"Periodical Inspection Part List"(p.3) and perform
cleaning and part replacement as necessary.
• Operation manual
• Separate sheet “Exploded view” P.2-P.10
8.2.1 Periodic Replacement Parts
The parts in the following table require replacement once per year.
8.2.2 Parts Which Require Inspection/Replacement
Table 8-1 Replacement Target Parts
Maintenance part names
(Maintenance part numbers)
Replacement parts Replacement procedure
VJ periodic maintenance kit (DG-
40075)
Damper assembly "4.6.1 Replacing PF Speed
Reduction Belt" p.4-60
Maintenance assembly "4.9 Replacing Maintenance
Section" p.4-121
Cleaner head assembly "4.7.3 Replacing CR Drive
Pulley Assembly" p.4-90
Table 8-2 Periodical Inspection Part List
Part Timing Check point Action
Media guide F
Platen front surface
Several times per
year
•Media dust
accumulation
• Foreign objects
• Damages
Clean it.
If ink deposits are
present, remove them
with a dampened cloth
and wipe the area with a
clean dry cloth.
Timing fence
(CR encoder detection
slit plate)
Several times per
year
•Media dust
accumulation
• Foreign objects
• Damages
Clean it.
If any damages are found,
replace the part.
