5 Self-Diagnosis Mode VJ-1604 Maintenance Manual
Rev.-05 5-8
5.3.2 Diagnosis Items in Self-Diagnosis Menu
The self-diagnosis menu includes the following diagnosis items.
Table 5-1 Diagnosis Items in Self-Diagnosis Menu
Diagnosis item Contents Reference
Platen Adjustment
Menu
Performs temperature setting for the platen heater to 42
° C. "5.4 Platen
Adjustment Menu"
p.5-10
Inspection Menu Performs various inspections for memory size, version,
panel, sensor, encoder, fan, head waveform, etc. Displays the
history.
"5.5 Inspection
Menu" p.5-11
Ink Charging Menu Performs ink charging. "5.6 Ink
Charging Menu"
p.5-22
Adjustment Menu Performs various adjustments for the plotter mechanism. "5.7
Adjustment Menu"
p.5-23
Cleaning Menu Performs cleaning of the print head. "5.8 Cleaning
Menu" p.5-47
Print Menu Performs sample printing necessary for adjustment. "5.9 Sample
Printing Menu" p.5-
48
Time Setting Menu Performs setting the time of the plotter. "5.10 Time
Check" p.5-51
Parameter Menu Configures various adjustment parameters. "5.11
Parameter Menu"
p.5-52
Servo Menu Performs adjustment for the servo motor. "5.12 Servo
Setting" p.5-62
Endurance Running
Menu
Performs endurance running of the plotter mechanism. "5.13
Endurance Running
Menu" p.5-65
Media feed Menu Feeds media into the plotter forward or backward. "5.14 Media
Feed Menu" p.5-71
ExControl Menu Performs diagnosis of the controller board version, sensor,
and heater check. Displays the history.
"5.15 ExControl
Menu" p.5-72
PaperInitial Menu Performs initialization and media detection setting. "5.16
PaperInitial Menu"
p.5-78
