4 Parts Replacement VJ-1604　 Maintenance Manual
Rev.-05 4-40
4.4 Replacing Board Base (X Rail Section)
This section describes the procedure to replace the power supply or the board in the X rail section.
The boards are arranged as follows.
No. Part name
1 HEATER RELAY board assembly
2 HEATER-CONT board assembly
3 Power board assembly
4 Main board assembly
2
4
1
3
Inside view of board box 64
Inside view of media guide F
To Next Page
