VJ-1604 Maintenance Manual 5 Self-Diagnosis Mode
5-35 Rev.-05
* Print pattern: Uni-D, 2 pass, 1A to 2B print
1st pass: prints middle dot
2nd pass: prints small dot
5.7.5 Uni-D/Bi-D Low/High Adjustment
Adjusts the gap of the print heads (in the CR moving direction) when the head is in the PG Low/High and the
print position of the head in repeatability printing.
To adjust, perform printing in repeatability printing and correct CW and CCW printing positions by inputting
parameters.
* Check the printing at the origin, center and the opposite side to origin, and perform adjustment so that the
gap is even.
Adjustment items are shown below.
Items Speed
240 CW CW 240 cps
320 CW CW 320 cps
240 CCW CCW 240 cps
320 CCW CCW 320 cps
Table 5-8 Uni-D / Bi-D Menu Items
Item Contents
Uni-D 240 Adjusts CW at 240 cps. PG Low or High
Uni-D 320 Adjusts CW at 320 cps. PG Low or High
Uni-D 240B Adjusts CW at 240 cps-Banner. PG Low or High
Uni-D 320B Adjusts CW at 320 cps-Banner. PG Low or High
Bi-D 240 Adjusts Bi-D at 240 cps. PG Low or High
Bi-D 320 Adjusts Bi-D at 320 cps. PG Low or High
Bi-D 240B Adjusts Bi-D at 240 cps-Banner. PG Low or High
Bi-D 320B Adjusts Bi-D at 320 cps-Banner. PG Low or High
Table 5-9 Uni-D / Bi-D Adjustment Items
Item Contents
Set up Sets the selected parameter.
Print (when Bi-D is
selected, Print 1 is
displayed)
Prints pattern according to the selected item with the
current parameter.
