VJ-1604 Maintenance Manual 4 Parts Replacement
4-95 Rev.-05
8. Detach the T fence from the T fence spring.
9. Detach the T fence from the T fence guide plate (3 pieces).
No. Part name
1 T fence spring
2 T fence spring hook
3T fence
No. Part name
1 T fence guide plate
2 T fence
1
2
3
2
1
