Table 8-6 Lubricant List
Parts Item Manufacturer Type
PF drive section Up/down gear
on pressure
lever
Apply to gear Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
PF motor
bracket /
Middle gear
inner diameter
Apply to middle
gear inner diameter
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Speed
reduction
pulley
Apply to drive
pulley
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Medium tray
slide, Grit
medium tray
Apply to the areas
the plates contact
each other.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
CR drive
section
Y rail
machining
diagram
Apply to the hole
securing Y drive
base.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Apply to the hole
securing the return
pulley bracket.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Y rail and
roller guide
While inserting
roller guide, apply
to the downside of
the roller guide.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Pressure shaft
bearing
Apply to the upside
and the shaft
insertion part.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Pressure cam Apply to cam part. Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Roller guide Apply to the front
surface of roller
guide.
Mitsubishi Super multi-dia
tetrat No.32
Drive pulley Apply to drive
pulley.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Cursor section Head U/D
collar
Apply to head U/D
collar.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Head U/D cam Apply to head U/D
cam.
Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
Slide gear Apply to gear. Kanto Kasei Co.,
Ltd.
FLOIL G-MK-1
