mycom 1612LSC series

2202L5JE-DA-C5-N_2015.05.
7 Related Documents
Compound 2-stage Screw Compressor 7.2 Parts Configuration Table
1612LSC Speed Increaser Type
7-6
P/N Part name Part code No. Remarks
Quantity
52/62 53/63 54
31 Key, Balance Piston CS03100-125 125***
1 1 1
32 Snap Ring C type External NG12-040 S40
1 1 1
33 Sleeve, Balance Piston CS03300-160 160***
1 1 1
34 Hexagon Socket Head Cap Screw NB35406-015 M6×15
1 1 1
35 O-ring PA12-095 JIS B 2401 G95
1 1 1
37 Snap Ring C type Internal NG11-102 H102
1 1 1
38-1 Thrust Bearing (1) A CS03800-1612CP 7214B
1set 1set 1set
38-1 Thrust Bearing (1) B CS03800-160P 7212B
1set 1set 1set
38-2 Thrust Bearing (2) CS03800-125P 7209B
2set 2set 2set
39-1 Lock Nut (1) A NG31-014 AN14
1 1 1
39-1 Lock Nut (1) B NG31-012 AN12
2 2 2
39-2 Lock Nut (2) NG31-009 AN09
2 2 2
40-1A Lock Washer (1) A NG32-014 AW14
1 1 1
40-1B Lock Washer (1) B NG32-012 AW12
2 2 2
40-2 Lock Washer (2) NG32-009 AW09
2 2 2
41-1 Spacer, Thrust Bearing Outer Race (1) CS04100-160 160***
1 1 1
41-2 Spacer, Thrust Bearing Outer Race (2) CS04100-125 125***
2 2 2
42-1A Spacer, Thrust Bearing Alignment (1) CS04200-1612C
1612LSC
speed increaser type
1 1 1
42-1B Spacer, Thrust Bearing Alignment (1) CS04200-B160 160*** Booster
1 1 1
42-2 Spacer, Thrust Bearing Alignment (2) CS04200-125 125***
2 2 2
43-1A Thrust Bearing Gland (1) A CS04300-1612C3M
16LSC
speed increaser type
1 1 1
43-1B Thrust Bearing Gland (1) B CS04300-1612C3F
1 1 1
43-2A Thrust Bearing Gland (2) A CS04300-1612C2F 1612**C
1 1 1
43-2B Thrust Bearing Gland (2) B CS04300-1612C2M 1612**C
1 1 1
45-1A Hexagon Head Bolt NB15512-035 M12×35
4 4 4
45-1B Hexagon Head Bolt NB15510-030 M10×30
4 4 4
45-2 Hexagon Head Bolt NB111008-030 M8×30
8 8 8
46-1A Spring Washer ND320-012 M12
4 4 4
46-1B Spring Washer ND320-010 M10
4 4 4
46-2 Spring Washer ND320-008 M8
8 8 8
48 Retainer, Oil Seal CS04800-160 160***
1 1 1
49 O-ring PA12-090 JIS B 2401 G90
1 1 1
50 Oil Seal CS05000-160VD SA1J55 × 70 × 9
1 1 1
51 Seal Cover CS05100-160 160***
1 1 1
52 Gasket, Seal Cover CS05200-160N 160***
1 1 1
53 Hexagon Socket Head Cap Screw NB35408-025 M8×25
8 8 8
54 Unloader Slide Valve (L Port) CS05400-1612C 1612LSC
1 1 1
54 Unloader Slide Valve (M Port) - 1612LSC
1 1 1
58 Hexagon Socket Head Cap Screw NB35408-030 M8×30
4 4 4
59 O-ring PA11-016 JIS B 2401 P16
1 1 1
60 Unloader Cylinder CS06000-1612C 1612**C
1 1 1
61 Hexagon Socket Head Cap Screw NB35408-095 M8×95
8 8 8
63 O-ring PA12-095 JIS B 2401 G95
1 1 1
64 Unloader Piston CS06400-1612C 1612**C
1 1 1
65 O-ring PA11-075 JIS B 2401 P75
1 1 1
66 Cap Seal CS06600-125 CAP-1BE75
1 1 1
67 Push Rod (3), Unloader Slide Valve CS06700-1612C3
16LSC
speed increaser type
1 1 1
68 Guide Pin NE2503-008 Φ3×8
1 1 1
69 Lock Nut NG31-005 AN05
1 1 1
70 Lock Washer NG32-005 AW05
1 1 1
71 Lock Nut NG31-006 AN06
1 1 1
72 Lock Washer NG32-006 AW06
1 1 1
73 O-ring PA11-021 JIS B 2401 P21
1 1 1
74 Unloader Cover CS07400-125S 125***
1 1 1
