mycom 1612LSC series

2202L5JE-DA-C5-N_2015.05.
7 Related Documents
Compound 2-stage Screw Compressor 7.2 Parts Configuration Table
1612LSC Speed Increaser Type
7-7
P/N Part name Part code No. Remarks
Quantity
52/62 53/63 54
75 O-ring PA12-085 JIS B 2401 G85
1 1 1
76 Hexagon Socket Head Cap Screw NB35406-035 M6×35
8 8 8
77 Indicator Cam CS07700-1610C 1610SLC
1 1 1
78 Ball Bearing CS07800-200 #6000
1 1 1
79 Snap Ring C type External NG12-010 S10
1 1 1
80 Bearing Gland CS08000-200 200***
1 1 1
81 Hexagon Socket Head Cap Screw NB35406-015 M6×15
3 3 3
82 V-ring CS08200-200B 20×10×12
1set 1set 1set
83 Spring CS08300-200 200***
1 1 1
84 Retainer, Indicator Cam Spring CS08400-200 200***
1 1 1
85 Oil Injection Pipe CS08500-160SUK 125L**/160S**
1 1 1
86 O-ring PA11-016 JIS B 2401 P16
1 1 1
87 Guide Block CS08700-160 160***
1 1 1
88 Stem, Guide Block " 160***
1 1 1
89 O-ring PA11-016 JIS B 2401 P16
2 2 2
91 Shaft Key (Coupling Key) CS09100-160 160***
1 1 1
92-1 Suction Flange (1) CS71400-125 MYK 125A (5")
1 1 1
92-2 Suction Flange (2) CS71400-080 MYK 80A (3")
1 1 1
93-1 Gasket, Suction Flange (1) CR72000-125N MYK125A (5")
1 1 1
93-2 Gasket, Suction Flange (2) CR72000-080N MYK 80A (3")
1 1 1
94-1 Hexagon Head Bolt NB12020-055 M20×55
8 8 8
94-2 Hexagon Head Bolt NB12020-055 M20×55
4 4 4
95-1 Discharge Flange (1) CS71400-080 MYK 80A (3")
1 1 1
95-2 Discharge Flange (2) CS71400-065 MYK 65A (2"1/2)
1 1 1
96-1 Gasket, Discharge Flange (1) CR72000-080N MYK 80A (3")
1 1 1
96-2 Gasket, Discharge Flange (2) CR72000-065N MYK 65A (2"1/2)
1 1 1
97-1 Hexagon Head Bolt NB12020-055 M20×55
4 4 4
97-2 Hexagon Head Bolt NB12010-055 M16×55
4 4 4
100 Mechanical Seal Assembly CS10000-160BT BOS-T1 160V**
1set 1set 1set
100 Mechanical Seal Assembly CS10002-160EBS BBS-E 160
1set 1set 1set
120 Unloader Indicator Assembly CS12000-1612F 1612LSC
1set 1set 1set
151 Driven Sleeve 1610**C
1 1 1
152 Drive Hub 1610**C
1 1 1
153 Driven Hub 1612**C
1 1 1
154 Stopper, Drive Sleeve 1610**C
2 2 2
155 Stop Ring RR-293(#10 用)
4 4 4
157 Key, Driven Hub
1 1 1
158 Key, Drive Hub
1 1 1
159 Set Screw NA83606-015 M6×15
1 1 1
160 Lock Nut NG31-008 AN08
1 1 1
161 Lock Washer NG32-008 AW08
1 1 1
162 Hexagon Socket Head Cap Screw NB35406-035 M6×35
5 5 5
163 O-ring PA12-025 JIS B 2401 G25
1 1 1
164 Retainer, Oil Injection Pipe CS16400-1612C
1 1 1
165 O-ring PA11-021 JIS B 2401 P21
1 1 1
166 Hexagon Socket Head Cap Screw NB35406-025 M6×25
4 4 4
168 Pipe Guide, Oil Injection CS16800-1612C 1612LSC
1 1 1
169 Speed Increaser Gear Casing CS16900-1610C 1610SLC
1 1 1
170 Gasket, Speed Increaser Gear Casing CS17000-1612CN 1612LSC
1 1 1
171 Speed Increaser Gear Casing Cover CS17100-1610C 1610SLC
1 1 1
172
Gasket, Speed Increaser Gear Casing
Cover
CS17200-1610CN 1610SLC
1 1 1
174-1 Speed Increaser Drive Gear (4P) CS17400-1610C52
52-2610rpm
62-3150rpm
1 - --
