2202L5JE-DA-C5-N_2015.05.
7 Related Documents
Compound 2-stage Screw Compressor 7.2 Parts Configuration Table
1612LSC Speed Increaser Type
7-8
P/N Part name Part code No. Remarks
Quantity
52/62 53/63 54
174-2 Speed Increaser Drive Gear (2P) CS17400-1612153
53-3610rpm
63-4350rpm
- 1 -
174-3 Speed Increaser Drive Gear (2P) CS17400-1612154 54-4350rpm
- - 1
175 Key, Speed Increaser Gear Shaft CS18000-1610CD 1610C
1 1 1
176 Gland, Speed Increaser Gear CS18100-1610CD 1610C, 4P
2 - -
179-1 Speed Increaser Driven Gear (4P) CS17900-1610C52
52-2610rpm
62-3150rpm
1 - -
179-2 Speed Increaser Driven Gear (2P) CS17900-1612153
53-3610rpm
63-4350rpm
- 1 -
179-3 Speed Increaser Driven Gear (2P) CS17900-1612154 54-4350rpm
- - 1
180 Key, Speed Increaser Driven Gear CS18000-1610CI 1610C
1 1 1
181 Gland, Speed Increaser Driven Gear CS18100-1610CIB 1610C, 4P
2 - -
183
Side Bearing Speed Increaser Driven
Gear
CS02700-125 125*** Main bearing
1 1 1
184 Spring Pin NE3204-010 Φ4×10
1 1 1
185
Roller Bearing,
Speed Increaser Driven
Gear Spindle
CS18500-1612C NU2212
1 1 1
186 Snap Ring C type Internal NG11-110 H110
1 1 1
187 Snap Ring C type External NG12-060 S60
1 1 1
188 Speed Increaser Gear Spindle CS18800-1612C
1 1 1
189 Thrust Bearing CS03800-200 200***
1set 1set 1set
190 Gland, Thrust Bearing CS19000-1610C
1 1 1
191 Hexagon Head Bolt NB111012-035 M12×35
4 4 4
192 Conical Spring Washer CS04600-200 M12
4 4 4
193 Lock Nut NG31-013 AN13
1 1 1
194 Lock Washer NG32-013 AW13
1 1 1
195 Hexagon Socket Head Cap Screw NB35412-040 M12×40
21 21 21
196-1 Oil Flow Control Throttle CS19600-M408 M4×8×Φ1.5
1 1 1
196-2 Oil Flow Control Throttle R1/8×Φ1.5
2 2 2
197 O-ring PA11-032 JIS B 2401 P32
1 1 1
237-1A Torsional Slip Washer (1) A CS23700-1612CB 1612**C
1 1 1
237-1B Torsional Slip Washer (1) B CS23700-160 160***
2 2 2
237-1
C
Torsional Slip Washer (1) C CS23700-200 200***
1 1 1
237-1
D
Torsional Slip Washer (1) D CS23700-250 250***
1 1 1
237-2 Torsional Slip Washer (2) CS23700-125 125***
2 2 2
250-1 Thrust Washer CS25000-1612C3
1612LSC
speed increaser type
1 1 1
267 Special Spring Washer ND330-08 M8
4 4 4
326 Gland, O-ring CS32600-1612C
1612LSC
speed increaser type
1 1 1
335 Special Spring Washer ND330-06 M6
1 1 1
456 Hexagon Socket Head Cap Screw NB35405-010 M5×10
4 4 4
605-1 Plug NF06-015 R1/2
1 1 1
605-2 Plug NF06-008 R1/4
1 1 1
607 Plug NF06-004 R1/8
1 1 1
The part code of the O-ring is the one assigned to NBR which is standard
material. When the material of the O-ring is other than NBR, a different part code
is used for each material.
If you are using O-rings made from other than the standard material, please
contact Mayekawa when placing an order.
To Next Page
