Compound 2-stage Screw Compressor 4032**C Parts Configuration Table
7-7
No.
Part Name
Code No.
Remarks
Q’ty.
18-1
Hexagon Socket Head Cap Screw
NB35930-100
M30×100
with captive washer
22
18-2
Hexagon Socket Head Cap Screw
NB35424-075
M24×75
22
18-3
Hexagon Socket Head Cap Screw
NB35424-095
M24×95
4
19-1
Alignment Pin with Groove and Hole
NE2320-100A
Φ20×100
2
19-2
Alignment Pin with Female Tread
NE2325-070A
Φ25×70
2
21-A
Plug
NF021-NPT02
NPT1/4
4
21-B
Plug
NF021-NPT03
NPT3/8
1
21-C
Plug
NF021-NPT04
NPT1/2
1
22
Balance Piston Cover
CS02200-320
320***
1
23
Gasket, Balance Piston Cover
CS02300-320N
320***
1
24
Hexagon Socket Head Cap Screw
NB35416-045
M16×45
11
25-1
Male Rotor (1)
-
4032S*C
1(S*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
-
4032M*C
1(M*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
-
4032L*C
1(L*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
-
4032LL*C
1 (LL*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
-
4032XL*C
1(XL*C)
26-1
Female Rotor (1)
25-2
Male Rotor (2)
-
4032*SC
1(*SC)
26-2
Female Rotor (2)
25-2
Male Rotor (2)
-
4032*MC
1(*MC)
26-2
Female Rotor (2)
25-2
Male Rotor (2)
-
4032*LC
1(*LC)
26-2
Female Rotor (2)
25-2
Male Rotor (2)
-
4032*LLC
1(*LLC)
26-2
Female Rotor (2)
27-1
Main Bearing (1) O-ring type
CS0270-4032N
No.27-1 + No.432-1
2
27-2
Main Bearing (2) O-ring type
CS0270-GRT
No.27-2 + No.432-2
2
28-1
Side Bearing (1) O-ring type
CS02800-4032N
No.28-1 + No.438-1
2
28-2
Side Bearing (2) O-ring type
CS0280-GRT
No.28-2 + No.438-2
2
29-1
Snap Ring (1) C type Internal
NG11-250
JIS B 2804 H250
4
29-2
Snap Ring (2) C type Internal
NG11-200
JIS B 2804 H200
4
30
Balance Piston
CS03000-320
320***
1
31
Key, Balance Piston
CS03100-320
320***
1
32
Snap Ring C type External
NG12-100
JIS B 2804 S100
1
33
Sleeve, Balance Piston
CS03300-320
320***
1
34
Set Screw
NE3206-014
Φ6×14
1
35
O-ring
PA12-190
JIS B 2401 G190
1
36
Spacer
CS03600-320
320***
1
37
Snap Ring C type Internal
NG11-200
JIS B 2804 H200
2
38-1A
Thrust Bearing (1) TPTB
CS03800-T400M
400*** for M rotor
Daido
1
38-1B
Thrust Bearing (1) TPTB
CS03800-T400F
400*** for F rotor
Daido
1
38-2
Thrust Bearing (2) Ball type
CS03800-320
320** Cast Retainer
2
