2201Q4JE-MY-C9-N_2018.01.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 4032**C Parts Configuration Table
7-10
No.
Part Name
Code No.
Remarks
Qty.
81-1
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
3
81-2
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
3
82-1
V-ring
CS08200-200B
VH10 NBR
1
82-2
V-ring
CS08200-200B
VH10 NBR
1
83-1
Spring
CS08300-200
200***
1
83-2
Spring
CS08300-200
200***
1
84-1
Retainer, Indicator Cam Spring
CS08400-400
400***
1
84-2
Retainer, Indicator Cam Spring
CS08400-200
200***
1
87-2
Guide Block (2)
CS08700-320
320***
1
88-2
Stem, Guide Block (2)
89-2
O-ring
PA11-024
JIS B 2401 P24
2
91
Shaft Key
CS09100-400
400***
1
92-1
Suction Flange (1) with hole
CZA01-300C16B
ANSI #300 16"
1
92-2
Suction Flange (2) with hole
CZA01-300C12B
ANSI #300 12"
1
93-1
Gasket, Suction Flange (1)
PL300-400
ANSI #300 16"
1
93-2
Gasket, Suction Flange (2)
PL300-300
ANSI #300 12"
1
94-1
Stud Bolt
NBU611/4-7UNC
1-1/4"
-7UNC×165mm
20
-
Hexagonal Nut, Stud Bolt
NCU1511/4-7UNC
1-1/4" -7UC
20
94-2
Stud Bolt
NBU611/8-7UNC
1-1/8"
-7UNC×150mm
16
-
Hexagonal Nut, Stud Bolt
NCU1511/8-7UNC
1 1/8" -7UC
16
95-1
Discharge Flange (1) with hole
CZA01-300C12B
ANSI #300 12"
1
95-2
Discharge Flange (2) with hole
CZA01-300C08B
ANSI #300 8"
1
96-1
Gasket, Discharge Flange (1)
PL300-300
ANSI #300 12"
1
96-2
Gasket, Discharge Flange (2)
PL300-200
ANSI #300 8"
1
97-1
Stud Bolt
NBU611/8-7UNC
1-1/8"
-7UNC×150mm
16
97-2
Stud Bolt
NBU607/8-9UNC
7/8" -9UNC×120mm
12
100
Mechanical Seal Assembly
CS10000-400
400*** BOD
1
100
Mechanical Seal Assembly
CS10001-400BBDR
400*** BBD FKM
1
100
Mechanical Seal Assembly
CS1002-400EBD
400*** BBD-E
1
120-1
Unloader Indicator Assembly (1)
CS12000-200F
200** 0-100%
1
120-2
Unloader Indicator Assembly (2)
CS12000-3225
3225C (2) 30-100%
1
125
Micro-Switch
CS12500-200
200*** Z15GW
4
127-1
Micro-Switch Cam (1)
CS12700-200F
200*** 0-100%
1
127-2
Micro-Switch Cam (2)
CS12700-322530
3225C (2) 30-100%
1
128
Hexagon Socket Head Set Screw
NA83604-005
M4×5
2
129
Potentiometer 200-1 k
CS1299-E10
with lead wire
2
137-1
Indicator Dial (1)
CS13700-200
200***
1
137-2
Indicator Dial (2)
CS13700-3225C
3225C (2) 30-100%
1
150-1
O-ring
PA12-290
JIS B 2401 G290
2
150-2
O-ring
PA12-220
JIS B 2401 G220
2
151
Drive Sleeve
CS15100-4032CN
4032**C
1
152
Drive Hub
4032**C
2
157
Key, Driven Hub & Drive Hub
CS15700-4032CH
24×16×111
single round
2
159
Set Screw
NA83610-016
M10×16
2
163
O-ring
PA12-065
JIS B 2401 G65
1
