TECHNICAL MANUAL - hyperion X5
EN CONTROL BOARDS DESCRIPTION
49
LED ID COLOR NAME ON BOARD DESCRIPTION
DL15 GREEN ACK Acknowledged signal from LOGIC board, always on.
DL16 GREEN XRAY X-ray emission signal from Power board. Normally off, on during emission.
DL17 GREEN SD_ON Not used.
DL18 YELLOW ACT LAN activity LED. Normally flashing.
DL19 GREEN LINK LAN connection estabilished. Normally on.
DL22 GREEN 3.3V 3.3V CPU tension present, normally on
DL23 GREEN 24V 24V tension present, normally on
DL24 GREEN 5.0V 5V CPU tension present, normally on
DL25 GREEN 1.2V 1.2V CPU tension present, normally on
DL32 GREEN 48V R axis Motor tension present, normally on
DL33 GREEN FCR R axis photocell. On if photocell is obscured or disconnected/broken.
DL35 GREEN Not used
DL36 GREEN FCX Not used
DL38 GREEN 48V Y axis Motor tension present, normally on
DL39 GREEN FCY Y axis photocell. On if photocell is obscured or disconnected/broken.
DL42 GREEN EXP_OK_PAN
Exposure OK signal from sensor, normally off.
DL43 GREEN PAN_IN
Sensor present, normally off. On if broken cable or sensor interface board is
disconnected.
DL46 GREEN PAN_ON
48V Sensor power supply ok. Normally on.
Off during standby or in error condition on sensor or interface board.
DL49 GREEN 48V 48V from power board on. Off during standby or in error condition.
DL51 GREEN ENB_PAN
48V enabled on sensor. Normally on.
Off during standby or in error condition on sensor or interface board.
DL53 GREEN CHIN_L Not used
DL54 GREEN CHIN_R Not used
