TECHNICAL MANUAL - hyperion X5
44
CONTROL BOARDS DESCRIPTION EN
3.2.1. CONNECTORS LIST
CONNECTOR DESCRIPTION
K17 Mains power supply
K4 Power switch live wire
K5 Power switch neutral wire
K12 External emergency button - optional
K11 Door interlock - optional
K10 X-ray button
K14 External signal lamps – Optional- Wires 1,2 ready - Wires 3,4 x-ray emission
K16 Power supply for “logic” board
J3 Not used
K21 Can bus connector
K15 Integrated emergency button (on column)
K9 Monobloc feedback
K18 Column lower endpoint photocell
K13 Column upper endpoint photocell
K22 Column anti-pinch switch
K2 Column motor thermal sensor
K1 Column motor power supply
K3 Monobloc power supply
3.2.2. FUSES AND DIP SWITCHES LIST
FUSE ID NOTES DESCRIPTION
FH1/FH2 Mains power supply fuse
FUSE 20AF250v 6.3x32 115V
FUSE 12AF 250v 6.3x32 230V
F2 Standby power fuse FUSE 2AT 230V
F1 48V output fuse FUSE 2,5AF 450V DC
DIP Switches
SW1 Always off, reserved use
3.2.3. LEDS LIST
LED ID COLOR NAME ON BOARD DESCRIPTION
DL1 YELLOW ACT
CAN communication activity: normally flashing. Problems on CAN bus If off or
on steady
DL2 RED ERR
Error status, normally off. Flashing upon startup, the number of flashes
represents the FW version. When ERR is on the number of flashes from CPU
LED represents the error code.
DL3 GREEN CPU
Normally flashing at 1Hz
10Hz during column movement or x-ray emission
When ERR is on the number of flashes from CPU LED represents the error
code.
DL4 YELLOW UP
Normally off, if on the upper column endpoint has been reached. Always on if
photocell damaged or disconnected.
DL5 YELLOW DN
Normally off, if on the upper column endpoint has been reached. Always on if
photocell damaged or disconnected.
DL6 RED STOP
Normally off, if on the anti-pich microswitch has been pushed. Always on if
microswitch damaged or disconnected.
DL8 YELLOW VAC
On when mains power supply is on.
Off during stand by or in case of issues with power amplifier on the board.
