Myray hyperion X5 - KEYBOARD BOARD 97661484; LOGO BOARD 97661539

TECHNICAL MANUAL - hyperion X5
52
CONTROL BOARDS DESCRIPTION EN
3.4.1. CONNECTORS LIST
CONNECTOR DESCRIPTION
K1 Sync signal and power supply for sensor, from LOGIC board.
K2 Sensor power supply, 2x 5V DC
K3 Sensor synchronization
3.4.2. LEDS LIST
LED ID DESCRIPTION
DL1 (VIN) 48V from LOGIC board
DL2 (VCC)
A
nalog 5V towards sensor
DL3 (VDD) Digital 5V towards sensor
3.5. KEYBOARD BOARD 97661484
3.5.1. CONNECTORS LIST
CONNECTOR DESCRIPTION
K1 Keyboard signals from LOGIC
3.6. LOGO BOARD 97661539
3.6.1. CONNECTORS LIST
CONNECTOR DESCRIPTION
K1 24V power supply fron Logic board
