Myray hyperion X5 - SYSTEM REQUIREMENTS

TECHNICAL MANUAL - hyperion X5
EN PC CONFIGURATION
5
1. PC CONFIGURATION
1.1. SYSTEM REQUIREMENTS
hyperion X5 needs two ethernet connections, one for generic communication purposes (this supports DHCP and can be
set up through the local network) and a second dedicate connection, which must set up as direct point-to-point between
the unit and the INTEL PRO 1000 network card on the PC.
The PC dedicate to image aquisition (from now on referred to as “Acquisistion server”) must respect the following system
specification. Such a PC can be purchased as an option directly from Cefla, the model is Lenovo ThinkCentre Edge 73
Tower.
System requirements:
PROCESSOR Intel H81, Intel Core i3 4150 (3.5GHz, 3MB L3 Cache, 1600MHz), Quad core
RAM 4GB
HD 500GB / 7200 rpm
DVD DVD+-RW DL
NETWORK 1 Eth Giga integrated + 1Intel(R) Gigabit CT Desktop Adapter PCI-e
O.S. WIN7 Pro 64bit
VIDEO CARD
A
MD Radeon HD 7450 PCI Express 2.0, 128 Bit, 1024 MB, DDR3
POWER SUPPLY 500W
Besides the configuration above also the following ones have been validated and tested as “Acquisition Server” for X5:
COMPONENT CONFIG 1 CONFIG 2 CONFIG 3 CONFIG 4
PROCESSOR 1 CPU INTEL XEON
E5-2630 - 2,3GHZ -
6 CORE
1 CPU INTEL I7 3770
- 3,4 GHZ – 4 CORE
1 CPU INTEL XEON
E5-1620 - 3.60 GHz -
4 CORE
1 CPU INTEL XEON
E3-1270 V3 – 3.50
GHz – 4 CORE
POWER SUPPLY >= 800 W >= 550 W >= 600 W >= 400 W
VIDEO CARD ATI RADEON HD 7770 OC GHZ EDIT. VAPORX 1GB GDDR5 ATI RADEON R7
250 1GB
HARD DISK 2 SATA HDD - 300
GB - 10K RPM
1 SATA HDD - 500 GB - 10K RPM
RAM 4 GB DDR3 8 GB DDR3 1600 MHZ
O.S. WINDOWS 7 PROFESSIONAL 64 BIT SP1
NETWORK 2 ETHERNET CARDS (AT LEAST ONE INTEL PRO -1000 )
OTHER MINIMUM SCREEN RESOLUTION 1280X1024, 64 MILLION COLORS
DVD+-RW DL
The following video cards have been tested and validated for use with hyperion X5:
VIDEO CARDS MINIMUM POWER SUPPLY
A
TI Radeon HD 4850 / 5770 – 1GB >= 450 W
A
TI Radeon HD 4870 / 4890 / 5850 / 5870 – 1GB >= 500 W
Sapphire Radeon HD 6750 / 6770 – VaporX – 1GB –
RAM GDDR5
>= 450 W
Sapphire Radeon HD 6850 / 6870 / 6950 / 7870 – VaporX
– 1GB – RAM GDDR5
>= 500 W
Sapphire Radeon HD 7770 – GHz Ed. - OC - VaporX –
1GB – RAM GDDR5
>= 500 W
Sapphire Radeon HD 6970 – VaporX – 2GB – RAM
GDDR5
>= 550 W
Sapphire Radeon HD 7850 - 1GB / 2GB - RAM GDDR5 >= 500 W
Sapphire Radeon HD 7870 - 2GB - RAM GDDR5 >= 500 W
Sapphire Radeon HD 7750 - OC - 1GB – RAM GDDR5 >= 400 W
A
MD FirePro W7000 – 4GB GDDR5 >= 400 W
A
MD/Sapphire Radeon R7 250 1GB – RAM GDDR5 >= 400 W
A
MD/Sapphire Radeon R7 260X - RAM 1GB DDR5 >= 500 W
A
MD/Sapphire Radeon R9 270 - RAM 2GB DDR5 >= 500 W
