3. Rudders
1. Assemble the upper and lower casting on the
rudderblade. Use a at screwdriver and grease.
2. Use the self locking slot for the nylock nut at the
port side of the casting.
3. Put the boat on a high support or a trailer to
allign the rudders high enough to lock down the
rudders.
4. First place the lower pin through the lower
casting.
5. Put the top pin through the lower casting.
6. Push the casting all the way down and check if
the retainer clip is over the casting.
8. Take the philips screw out of the tillerarm.
24
Tools needed:
- Wrench 7/16 2x - Philips screwdriver
- Measurement tape - Flat screwdriver
- Grease - 3mm drill
7. Lower the blades and lock both systems.
