4 Select your local network from the drop down SSID list - NADLAB
(WPA2 CCMP) in this example.
5 Type the WPA Passphrase (if it is password protected) of your local
network in the eld provided and then select Go to join in.
6 A Warning notice will pop-up. Select OK to save the new settings. The
ashing signal bar indicator turns to solid bar. Your iOS device (iPad)
is now interfaced with the D 7050.
7 Return to the Wi-Fi settings of your iOS (iPad) device and ensure that it
is set to the same network setting as above (NADLAB).
NOTE
Setting up D 7050 as an Access Point is not only limited to the use of an
iPad or any iOS devices. Check Wireless Network connection procedure
and corresponding web browser for other operating systems like
Windows, OS X or Android in order to establish network connection and
setup D 7050 as an Access Point.
SHARE WIFI SETTINGS
WiFi connection can also be achieved by directly connecting your iOS
device to the DOCK input of the D 7050. Follow below procedure for
automatic network detection and connection.
1 Using applicable Apple USB cable (not supplied), connect iOS device to
DOCK input at the rear panel of D 7050 to share WiFi settings.
2 Short press WPS button located at the rear panel of D 7050. A ashing
signal strength bar indicator appears in the upper right corner of
the D 7050 display.
3 A Share Wi-Fi Settings notice will pop-up.
4 Select Allow to complete sharing of WiFi settings.
5 Wireless connection is established when the ashing signal bar
indicator turns to solid bar. Upon successful WiFi sharing, you can
disconnect the iOS device from the D 7050.
AIRPLAY PLAYBACK
After your AirPlay-enabled device and D 7050 are connected to the same
network, the Airplay source will detect the D 7050. Select the AirPlay icon
( ) that appears in the application display and select the unique ID of
your D 7050 (D 7050 00EBC8 in the example below).
Audio from your AirPlay-enabled device will be streamed to the D 7050.
IMPORTANT NOTE
When a connected Airplay source is activated to broadcast or playback
a song, the D 7050 will immediately switch to Airplay source mode
regardless of the current source.
CONNECT TO BLUETOOTH DEVICE
Pair Bluetooth device with the unique device ID of D 7050 (D 7050_BT
010DB6 in this example). Upon successful pairing, select BT as a source and
start music playback from your Bluetooth device.
OTHER FEATURES
11
