AUDIO SPECIFICATIONS
Rated power at 4 ohms 50W
Signal-to-Noise ratio (A-weighted) ≥ 90 dB
Crosstalk (1 kHz) ≥ 85dB
Crosstalk (10 kHz) ≥ 70 dB
Frequency response (20 Hz – 20 kHz) 0 dB to - 0.3 dB
Total Harmonic Distortion ≤ 0.004 %
IMD (SMPTE) 0.02 %
IMD (CCIF) 0.003 %
GENERAL SPECIFICATIONS
Standby power ≤ 0.5W
Supports bit rate/sample rate up to 24/192 (via Digital Audio input)
up to 24/96 (via Computer/Type B USB input)
Unit dimensions
W x H x D (Gross)
70 x 235 x 275 mm
2 / x 9 / x 10 / inches
Shipping weight 3.3 kg (7.3 lbs)
NAD SHALL NOT BE HELD LIABLE FOR ANY TECHNICAL OR USER INTERFACE DISCREPANCIES IN THIS MANUAL. THE D 7050 OWNER’S MANUAL MAY BE
SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. CHECK OUT WWW.NADELECTRONICS.COM FOR THE LATEST VERSION OF THE D 7050 OWNER’S MANUAL.
SPECIFICATIONS
18
