NAD L75 - Page 40

3-54
R111 ~ R124 KRD20TJ104T RES , CARBON 100K OHM 1/5W J
R125 ~ R128 KRD20TJ471T RES , CARBON 470 OHM1/5W J
R129 ~ R131 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN84 KJP12GB99ZM CONNECTOR MOLEX 35237-1210
JK11 , JK12 KJJ4P039Z JACK , BOARD JK0400451G
JK13 KJJ4R011Z JACK , IN/OUT(R/W,G) JK0600921G
PCB3 KUP1396-3 PCB , AUDIO BUFFER
C122 , C123 KCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C124 , C125 KCEA1VH101T CAP , ELECT 100UF 35V
C126 , C127 KCEA1HKS4R7T CAP , ELECT 4.7UF 50V
C128 , C129 KCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C130 , C131 KCEA1HKS4R7T CAP , ELECT 4.7UF 50V
IC12 BVIOPA2134UA I.C , OP AMP OPA2134UA
R132 ~ R135 KRD20TJ101T RES , CARBON 100 OHM 1/5W J
R136 ~ R141 KRD20TJ563T RES , CARBON 56K OHM 1/5W J
BN11 KJP06GB99ZM RES , CARBON MOLEX 35237-0610
BN12 KJP07GB99ZM CONNECTOR , HOUSING MOLEX 35237-0710
CN84 KJP12GA98ZM WAFER MOLEX 35336-1210
PCB4 KUP11396-4 PCB , VIDEO INPUT
C201 KCCT1H470JC CAP , CERAMIC 47PF 50V J
C202 , C203 KCCT1H220JC CAP , CERAMIC 22PF 50V J
C204 KCCT1H470JC CAP , CERAMIC 47PF 50V J
C205 KCCT1H220JC CAP , CERAMIC 22PF 50V J
C206 ~ C208 KCEA1CKS100T CAP , ELECT 10UF 16V
C209 ~ C212 KCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C213 ~ C216 KCEA1AKS101T CAP , ELECT 100UF 10V
IC23 BVINJM2296M I.C , VIDEO SW NJM2296M
R201 ~ R205 KRD20TJ750T RES , CARBON 75 OHM 1/5W J
R206 , R207 KRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R208 , R209 KRD20TJ4R7T RES , CARBON 4.7K OHM 1/5W J
R210 ~ R213 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN21 KJP09GB99ZM CONNECTOR MOLEX 35237-0910
JK21 KJJ4S003Z TERMINAL , INPUT IJBB3-N03-Z
JK22 KJJ4N007Z TERMINAL , INPUT IJBB2-N07
PCB5 KUP11396-5 PCB , SVIDEO INPUT
C221 , C222 KCCT1H470JC RES , CERAMIC 47PF 50V J
C223 , C226 KCCT1H220JC RES , CERAMIC 22PF 50V J
C227 , C228 KCCT1H470JC RES , CERAMIC 47PF 50V J
C229 , C230 KCCT1H220JC RES , CERAMIC 22PF 50V J
C231 ~ C236 KCEA1CKS100T CAP , ELECT 10UF 16V
C237 ~ C242 KCBS1H223ZFT CAP , CERAMIC 0.022UF 50V J
C243 ~ C248 KCEA1AKS101T CAP , ELECT 100UF 10V
IC21 , IC22 BVINJM2296M I.C , VIDEO SW NJM2296M
R221 ~ R230 KRD20TJ750T RES , CARBON 75 OHM 1/5W J
R231 ~ R234 KRD20TJ332T RES , CARBON 3.3K OHM 1/5W J
R235 ~ R238 KRD20TJ4R7T RES , CARBON 4.7K OHM 1/5W J
R239 ~ R246 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
BN22 KJP11GB99ZM KJP11GB99ZM MOLEX 35237-1110
JK23 KJJ9S001Z KJJ9S001Z C50360292N
JK24 KJJ9N004Z KJJ9N001Z C50360282N
SW21 KSS2D004Z KSS2D004Z JSS4208A
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
