NAD L75 - Page 41

3-55
LOAD NO. PART NO. DESCRIPTION SPECIFICATION
PCB7 KUP11396-7 PCB , GUIDE
C859 ~ C864 KCBS1H220JC CAP , CERAMIC 22PF 50V J
C881 KCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C882 KCEA1AKS101T CAP , ELECT 100UF 10V
C883 KCKT1H182KB CAP , CERAMIC 1800PF 50V K
C884 KCEA1VH100T CAP , ELECT 10UF 35V
D820 KVD1N4148MT DIODE 1N4148
Q808 KVTKC3198YT T.R KTC3138Y
R825 , R826 KRD20TJ103T RES , CARBON 10K OHM 1/5W J
R828 , R829 KRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R874 ~ R876 KRD20TJ272T RES , CARBON 2.7K OHM 1/5W J
R877 KRD20TJ103T RES , CARBON 10K OHM 1/5W J
R891 KRD20TJ103T RES , CARBON 10K OHM 1/5W J
R892 KRD20TJ472T RES , CARBON 4.7K OHM 1/5W J
R893 KRD20TJ101T RES , CARBON 100 OHM 1/5W J
BN81 BJP26GA132ZK FLEXIBLE CONNECTOR(SOCKET) TMC-D26X-A1
CN01 KJP15GB116ZG WAFER , CARDCABLE GF120-15S-LS
BN01 KWC1C4A15B060B CARDCABLE HTS-064-05NG
CN12 KJP07GA98ZM WAFER MOLEX 35336-0710
CN42 KJP13GA98ZM WAFER MOLEX 35336-0310
PCB8 KUP11396-8 PCB , HEADPHONE
BN78 KWBIC004070BM WIRE ASS'Y
JK25 BJJ2E020Z JACK
AMP B'D (KUP11397-1,2)
PCB1 KUP11397-1 PCB , FRONT AMP
C501 , C502 KCEA1VH100T CAP , ELECT 10UF 35V
C503 , C504 KCKT1H471KB CAP , CERAMIC 470PF 50V K
C505 , C506 KCEA1CH221T CAP , ELECT 220UF 16V
C507 , C508 KCCT1H150JC CAP , CERAMIC 15PF 50V J
C509 , C510 KCKK1H181KB CAP , CERAMIC 180PF 50V K
C511 , C512 KCQI1H223JZT CAP , MYLAR 0.022UF 50V J
C517 , C518 KCQI1H223JZT CAP , MYLAR 0.022UF 50V J
C519 , C520 KCEA1HH100T CAP , ELECT 10UF 50V
C529 , C530 KCKT1H331KB CAP , CERAMIC 330PF 50V K
C751 KCQI1H104JZT CAP , MYLAR 0.1UF 50V J
C752 , C754 KCEA1HH100T CAP , ELECT 10UF 50V
C755 KCEA1CH101T CAP , ELECT 100UF 16V
C756 KCQI1H563JZF CAP , ELECT 0.056UF 50V J
C780 KCKT1H331KB CAP , CERAMIC 330PF50V K
D501 ~ D506 KVD1N4148MT DIODE 1N4148
D751 ~ D754 KVD1N4148MT DIODE 1N4148
D757 , D758 KVD1N4148MT DIODE 1N4148
Q501 ~ Q506 KVTKTA1268GRT T.R KTA1268GR
Q507 , Q508 KVTKTC3200GRT T.R KTC3200GR
Q509 , Q510 KVTKTA1268GRT T.R KTA1268GR
Q511 , Q512 KVTKTC3200GRT T.R KTC3200GR
Q527 , Q528 KVTKSC2785YT T.R KSC2785Y
Q751 , Q752 KVTKTA1271YT T.R KSA1271Y
Q753 KVTKSC2785YT T.R KSC2785Y
Q755 , Q756 KVTKSC2785YT T.R KSC2785Y
Q757 KVTKTA1271YT T.R KTA1268GR
Q758 KVTKRA107MT T.R KRA107M
Q759 KVTKSC2785YT T.R KSC2785Y
R501 , R502 KRD20TJ102T RES , CARBON 1K OHM 1/5W J
