NAD T 753 - Exploded View Parts List

56
EXPLODED VIEW PARTS LIST
1 176-201123-04 FAN DC 60 X 60 X 10mm 12V 0.09A 3000RPM 2
MGA6012LR-A10(L) W/450mm CONNECTOR
(RoHS) R.1
2 176-201123-05 FAN DC 60 X 60 X 10mm 12V 0.09A 3000RPM 2
MGA6012LR-A10(L) W/350mm CONNECTOR
(RoHS) R.1
3
177-022005-03 TRANSFORMER PW EI-114 115V/230V T753 1
T06675A (RoHS)
4 181-000000-09 FAN GUARD 60mm DFG-60 4
5 275-006103-00 JUMPER PLUG PITCH 14mm 6
6
275-010100-00 AC SOCKET IEC 10A/250V 1
7
275-010100-05 AC OUTLET 3 PINS US POLARIZED 1
SS-6B-1-NY [FOR AH & AHT VER.]
275-010000-03 AC OUTLET EURO CEE 7 2.5A/250V 1
A302D0060P [FOR C & CT VER.]
8 560-400000-02 AM/FM TUNER MODULE KST-MB114MA0-23 1
(ROHS)
560-400000-00 AM/FM TUNER MODULE KST-MB114MA1-23 1
(ROHS) [FOR C & CT VER.]
9 601-020050-02 SELF TAPPING SCREW 2X5 WASHER 8
HEAD TYPE [B] NI PLT (RoHS)
10 601-026050-00 SELF TAPPING SCREW DIA2.6 X 5 P/H 2
TYPE [A] NI PLT (RoHS)
11 601-026060-00 SELF TAPPING SCREW DIA2.6 X 6 P/H 6
TYPE [A] NI PLT (RoHS)
12 601-026080-01 SELF TAPPING SCREW DIA2.6 X 8 B/H 14
TYPE [A] NI PLT (RoHS)
13 608-140260-01 RUBBER FOOT I/D14 X O/D26 X 3 PORON 4
HH-48C
14 610-030024-00 NUT M3 X 2.4mm (RoHS) 16
15 610-040032-00 NUT M4 X 3.2mm 0.7p 2
16 610-050034-00 NUT M5X3.4 NI PLT 4
17 610-090022-00 NUT ZINC PLATED M9.0 X 2.2mm 11p 1
18 614-030008-01 TAPTITE SCREW 3 X 8 SMALL K/H TYPE [B] 2
BLK PLT (RoHS)
19 614-030018-00 MACHINE SCREW M3 X 18 P/H NI PLT (RoHS) 16
20 614-030060-00 MACHINE SCREW M3 X 6 P/H NI PLT (RoHS) 17
21 614-030060-01 MACHINE SCREW M3 X 6 P/H BLK (RoHS) 2
22 614-030060-03 MACHINE SCREW M3.0 X 6.0 B/H TAP 20
TYPE NICKEL PLT (RoHS)
23 614-030060-11 TAPTITE SCREW 3 X 6 B/H TYPE [B] BLK (RoHS) 4
24 614-030080-00 MACHINE SCREW M3 X 8 P/H NI PLT (RoHS) 5
25 614-030080-05 SELF TAPPING SCREW DIA3 X 8 B/B ZINC 32
PLD TAPTITE-TYPE (RoHS)
26 614-030080-10 MACHINE SCREW M3 X 8 B/H BLACK (RoHS) 2
27 614-030080-13 TAPTITE SCREW DIA3 X 8 B/H TYPE [B] 54
BLK PLT (RoHS)
28 614-030100-04 TAPTITE SCREW DIA3 X 10 P/H TYPE [B] 7
BLK (RoHS)
29 614-030120-02 MACHINE SCREW M3 X 12 B/H NI-PLT (RoHS) 20
30 614-035080-04 TAPTITE SCREW 3.5 X 8.0 B/H TYPE [B] 5
NI PLT (RoHS)
31 614-040080-03 MACHINE SCREW M4 X 8 WASHER HEAD 6
BLK (RoHS) [FOR GREY VER.]
31 614-040080-02 MACHINE SCREW M4 X 8 WASHER HEAD 6
NI PLT (RoHS) [FOR TITANIUM VER.]
32 614-040080-06 TAPTITE SCREW DIA4 X 8 B/H BLK TYPE-B 4
(RoHS)
Item Database Part No. Description Qty.
