NAD T 753 - Page 9

9
WIRING DIAGRAM PARTS LIST
Item Database Part Number Description Remark
1 276-022613-06 CABLE ASSY 2 WAYS AWG=26 2.5P UL2468 AMP1 BD-
L=440mm J511A
2 276-041823-11 CABLE ASSY 4 WAYS AWG=18 3.96P UL1007 AMP1 BD-
L=420mm YB03053103-03A J581A
3 276-062613-22 CABLE ASSY 6 WAYS AWG=26 2.5P UL1007 AMP1 BD-
L=320mm (RoHS) J503A
4 276-041823-02 CABLE ASSY 4 WAYS AWG=18 3.96P UL1007 AMP2 BD-
L=200mm REV.B (RoHS) J781B
5 276-042613-08 CABLE ASSY 4 WAYS AWG26 2.5P UL1533 AUDIO BD-
L=450MM (ROHS) J3103A
6 276-022613-07 CABLE ASSY 2 WAYS AWG=26 2.5P UL1533 DIGIT BD-
L=540mm (ROHS) J1009A
7 276-042613-06 CABLE ASSY 4 WAYS AWG=26 2.5P UL2468 DIGITAL BD-
L=540mm J1010A
8 276-011843-01 CABLE ASSY 1 WAY AWG18 UL1007 BLACK KEYBOARD-
L=100mm W/ RING TERMINAL (RoHS) J201
9 276-052613-08 CABLE ASSY 5 WAYS AWG26 2.5P UL1007 LED BD-
L=160mm (RoHS) J204A
10 276-011843-03 CABLE ASSY 1 WAY AWG=18 UL1007 BLACK MAIN BD-
L=360mm W/ RING TERMINAL J701
11 276-032613-18 CABLE ASSY 3 WAYS AWG=26 2.5P L=110mm MAIN BD-
J6106B
12 276-032613-19 CABLE ASSY 3 WAYS AWG=26 2.5P L=60mm MAIN BD-
J6105B
13 276-032613-29 CABLE ASSY 3 WAYS AWG26X2C UL2547 MAIN BD-
L=210mm (UL LABEL) (RoHS) J715A
14 276-082613-22 CABLE ASSY 8 WAYS AWG=26X3C MAIN BD-
L=480mm (RoHS) J709A
15 276-102613-14 CABLE ASSY 10 WAYS AWG26 2.5P UL1007 MA BD-
L=460mm (UL LABEL) J350B
16 276-122613-16 CABLE ASSY 12 WAYS AWG26 2.5P UL2468 MA BD-
L=230mm (UL LABEL) (RoHS) J502B
17 276-142613-02 CABLE ASSY 14 WAYS #26 2.5P UL1007 MA BD-
L=540mm (RoHS) J8101B
18 276-031823-09 CABLE ASSY 3 WAYS AWG=18 3.96P UL1015 SPK BD-
L=320mm J782B1,
J782B2,
J782B3
19 276-031823-11 CABLE ASSY 3 WAYS AWG=18 3.96P UL1015 SPK BD-
L=350mm J582B1,
J582B2,
J582B3
20 276-051823-07 CABLE ASSY 5 WAYS AWG=18 3.96P UL1007 SPK BD-
L=250mm (V/BL/Y) J801B1,
J801B3,
J801B5
21 276-051823-09 CABLE ASSY 5 WAYS AWG=18 3.96P UL1007 SPK BD-
L=120mm (BR/R/O) J501B1,
J501B3,
J501B5
22 276-031823-16 CABLE ASSY 3 WAYS AWG=18 3.96P UL1015 SPK BD-
L=240mm REV.C J504B1,
J504B3
23 276-062613-05 CABEL ASSY 6 WAYS AWG=26 2.5P PO BD-
UL1533X1C L=350mm (RoHS) J612A
24 276-062613-09 CABLE ASSY 6 WAYS AWG=26 2.5P PO BD-
UL 1533X1C L=540mm REV.B J611A
