EXPLODED VIEW PARTS LIST
ITEM PART NO. DESC. QTY
1 08-002-0067-90 FAN DC 60x20mm 12V 0.18A 3800RPM DF126020SL 2
L=430mm w/ 2.5P CONNECTOR (RoHS)
2 08-002-0068-90 FAN DC 60x20mm 12V 0.18A 3800RPM DF126020SL 3
L=330mm w/ 2.5P CONNECTOR (RoHS)
3 10-005-0272-90 TRANSFORMER PW TOROIDAL 120V T775 1
AT4.531.0098 TA-1000 (RoHS) [FOR 120V VERSION]
10-005-0273-90 TRANSFORMER PW TOROIDAL 230V T775 1
AT4.531.0098/2 TA-1000 (RoHS) [FOR 230V VERSION]
4 11-001-0062-90 SWITCH ROCKER 1P1T BLK/BLK 10A/250VAC TV-5 1
UL/CSA/VDE/SEMKO (RoHS)
5 15-004-0074-90 AC SOCKET IEC 10A 250V JR-101 (RoHS) 1
[FOR 120V VERSION]
15-004-0075-90 AC INLET 10A 250V R-301 RICH BAY 1
UL/CCC/VDE/N/S (RoHS) [FOR 230V VERSION]
6 15-004-0078-90 AC OUTLET 3 PINS US POLARIZED SS-6B-1-NY 1
(RoHS) [FOR 120V VERSION]
15-004-0076-90 AC OUTLET EURO CEE 7 2.5A/250V A302D0060P 1
(RoHS) [FOR 230V VERSION]
7 15-016-0001-90 AM/FM TUNER MIDULE KST-MB114MA0-23 (RoHS) 1
8 19-001-0088-91 EXT. HTSK LEFT T775 (ROHS) 1
9 19-001-0089-91 EXT. HTSK RIGHT T775 (RoHS) 1
10 19-001-0090-90 U-SHAPE EXT. HTSK T775 (RoHS) 1
11 19-001-0093-91 HEATSINK-RECTIFER T762 (RoHS) 1
12 19-001-0116-90 HEATSINK PLATE TRANSISTOR 2.5MM 7
ALUMINIUM (RoHS)
13 21-001-0030-90 NEW VOLUME KNOB ASSY T175 GRAPHITE (RoHS) 1
[FOR GRAPHITE VERSION]
21-001-0031-90 NEW VOLUME KNOB ASSY T175 TITANIUM (RoHS) 1
[FOR TITANIUM VERSION]
14 21-002-0155-90 POWER BUTTON TACT ACTIVE T765 GRAPHITE 1
(RoHS) [FOR GRAPHITE VERSION]
21-002-0156-90 POWER BUTTON TACT ACTIVE T765 TITANIUM 1
(RoHS) [FOR TITANIUM VERSION]
15 21-002-0157-90 2X BUTTON SET T765 GRAPHITE (RoHS) 2
[FOR GRAPHITE VERSION]
21-002-0158-90 2X BUTTON SET T765 TITANIUM (RoHS) 2
[FOR TITANIUM VERSION]
16 21-002-0159-90 4 WAYS BUTTON T765 GRAPHITE (RoHS) 1
[FOR GRAPHITE VERSION]
21-002-0160-90 4 WAYS BUTTON T765 TITANIUM (RoHS) 1
[FOR TITANIUM VERSION]
17 21-002-0161-90 CENTER BUTTON T765 GRAPHITE (RoHS) 1
[FOR GRAPHITE VERSION]
21-002-0162-90 CENTER BUTTON T765 TITANIUM (RoHS) 1
[FOR TITANIUM VERSION]
18 22-001-0043-00 SCREW MACHINE M3 x 6 P/H WASHER HEAD 3
NI PLT (RoHS)
19 22-001-0367-00 SCREW MACHINE M3 x 6 P/H NI PLT (RoHS) 11
20 22-001-0376-90 MACHINE SCREW M3 x 6 P/H BLK (RoHS) 3
21 22-001-0379-90 MACHINE SCREW M4 x 8 WASHER HEAD BLK 6
(RoHS)
22 22-001-0381-90 MACHINE SCREW M3 x 10 PAN HEAD NI PLT (RoHS) 18
23 22-001-0384-90 MACHINE SCREW M4 x 14 WASHER HEAD BLK 1
(RoHS)
24 22-001-0409-90 SCREW MACHINE M3 x 15 WASHER HEAD 20
W/ STOPPER NI PLT (RoHS)
