NAD T 775 - Electrical Parts List

68
ELECTRICAL PARTS LIST
POWER AMP MODULE ***SEE PAGE 124 FOR SINGLE CHANNEL SERVICE KIT # 52-940-0765-90
PCB ASSEMBLY 50-940-0765-90 T765/T775 PWR AMP MODULE
MAIN BOARD
PCB ASSEMBLY 50-901-0765-90 T765/T775/T785 AH MAIN ASSY
REGULATORS
U7001-7002 U7004 01-004-0048-00 IC VOLT REG 5V 1A TO-220 NJM7805FA
U7003 U7005 01-004-0049-00 IC VOLT REG 12V 1A TO-220 NJM7812
U7006 01-004-0051-00 IC VOLT REG TO-220F NJM7912
U7007 01-004-0054-90 IC REG 1A TO-220(T) LM317T
RESISTOR
R7006 02-004-0014-00 RES FUSIBLE 0.22 OHM 10% 1/2W
CAPACITORS
C7002-7003 C7006 03-001-0060-00 CAP CER 0.1uF 50V 20% Y5V
C7009-7010 C7015-7016
C7018 C7021 C7023-7024
C7027-7028 C7030 C7033
C7005 C7011 C7017 C7020 03-002-0066-00 CAP ELEC KM 1000uF 25V 20% 105C
C7026 C7031
C7022 C7025 C7019 C7032 03-002-0151-00 CAP ELEC 2200uF 25V 20% 105C
C7007 03-002-0153-00 CAP ELECT 330uF 50V 20% 85C
C7001 C7004 03-002-0160-00 CAP ELEC SK 6800uF 35V 20% 105C
C7008 C7029 03-002-0168-00 CAP ELEC SK 4700uF 25V 20% 105C
DIODES
D7004 D7006 04-001-0003-00 Diode 1N4007 DO-41 1A/1000V
D7003 04-005-0020-90 DIODE BRI 4A/70V RS402L
D7001-7002 04-005-0022-90 DIODE BRI 6A/600V RS605
RESISTORS
R7001 02-001-0442-00 RES CF 33K OHM 5% 1/6W
R7002 02-002-0129-00 RES MF 1K OHM 1% 1/6W
R7003 02-002-0134-00 RES MF 3.3K OHM 1% 1/6W
JUMPERS
JMP7 JMP9 JMP11 JMP13-17 JMP19-21 17-016-0077-00 Jumper wire Dia. 0.5mm L=52.0mm
JMP23 JMP25 JMP31 JMP33 JMP35
D7005 JMP1-4 JMP6 JMP8 JMP10 17-016-0080-90 Jumper Wire Dia. 0.5mm For L Smaller
JMP12 JMP18 JMP22 JMP24 JMP26-28 than 14mm
JMP32 JMP34 JMP36
PSU BOARD
PCB ASSEMBLY *AH 50-903-0775-90 T775 AH PSU ASSY
PCB ASSEMBLY *C CT 50-904-0775-90 T775 C/CT PSU ASSY
RESISTORS
R8005*AH 02-001-0451-00 RES CONDUCTIVE PATH 3.9M OHM
1/2W 5% 250V
R8003 02-004-0014-00 RES FUSIBLE 0.22 OHM 10% 1/2W
