NAD T 775 - Page 71

69
NTC
R8006 02-004-0016-90 NTC SL32-1R030 30A/265V
CAPACITORS
C8002 03-002-0148-00 CAP ELEC SS 4.7uF 50V 20% 85C
C8001 03-004-0115-00 CAP MpF 0.001uF 63V 5% DMF 5
SERIES
C8006 03-007-0014-00 HC CER CAP 0.01uF/250VAC ±20%
UL/CSA/VDE
DIODES
D8001-8006 04-001-0003-00 Diode 1N4007 DO-41 1A/1000V
TRANSISTORS
Q8001 05-001-0072-00 Transistor SS NPN HEF 100 200MHs
TO-92 C1815Y
RELAYS
M8002*AH 07-005-0056-90 RELAY POWER DC 12V 20A 220VAC
ME-14FW-012-HTS(AgSno) UL/CUL
M8002*C CT 07-005-0044-90 RELAY MINIATURE 12VDC/10A 1P1T
TV-5 SDT-SS-112DM S/CSA/UL
STANDBY-TRANSFORMER
T8001 10-005-0186-90 Transformer PW EL-35 100V/220V
T05382B
FUSES
F8002*C CT 20-001-0069-90 FUSE TIME-LAG 800mA 250V 5x20mm
TSD UL/CSA/VDE/CCC
F8001*C CT 20-001-0072-90 FUSE TIME-LAG 6.3A 250V 5X20mm
TSD UL/CSA/VDE/CCC
F8002*AH 20-001-0076-90 FUSE TIME LAG 1.6A 250V 5x20mm
TSD UL/CSA/VDE/SEMKO
F8001*AH 20-001-0078-90 FUSE TIME-LAG 10A/250V 5X20mm
UL/CSA 5T
FH8001 FH8002 20-002-0030-90 FUES CLIP 5.2X20mm WL-210A 10A
250V
JUMPERS
JMP1 JMP2 JMP4-5 17-016-0077-00 Jumper wire Dia. 0.5mm L=52.0mm
JMP3 JP8001*C CT JP8002*AH R8006 17-016-0080-90 Jumper Wire Dia. 0.5mm For L Smaller
than 14mm
RIGHT POWER AMP BOARD ***SEE PAGE 124 FOR SINGLE CHANNEL SERVICE KIT # 52-940-0765-90
PCB ASSEMBLY NSP T765 Right Amp Board AssembLY NSP
IC & REGULATOR
U5403 01-004-0049-00 IC VOLT REG 12V 1A TO-220 NJM7812
U5402 01-020-0026-90 IC LM35DT TEMP SENSOR TO-220
RESISTORS
R5028 R5030 R5128 R5130 02-005-0063-00 RES WW 0.22 OHM 5% 5W AXIAL
R5228 R5230 R5328 R5330
R5036 R5136 R5236 R5336 02-010-0014-00 RES MO 10 OHM 5% 2W AXIAL
