72
Q5008 Q5108 Q5208 05-004-0019-00 SMD Transistor MMBT5401LT1G PN
Q5308 Q5408 Q5406 PCAP ELEC SMD SOT-23
Q5010 Q5110 Q5210 Q5310 05-004-0030-90 XTR 2SD1918 NPN POWER 160V/1.5A
80MHz HFE 120-390 SMD
Q5006 Q5007 Q5009 Q5106 Q5107 05-004-0031-90 XTR 2SB1275 PNP POWER 160V/1.5A
Q5109 Q5206 Q5207 Q5209 Q5306 50MHz HFE 82-180 SMD
Q5307 Q5309
Q5410 05-004-0032-90 XTR N-CH 2SK771-4 40V 20mA
IDSS=2.5 - 6 mA SMD
Q5407 05-004-0035-90 TRANSISTOR SS NPN HFE30 250MHz
SPT DTC114EKAT146
Q5401-5405 05-004-0036-90 TRANSISTOR SS NPN HFE20 250MHz
DTC123EKAT146
LEFT POWER AMP BOARD ***SEE PAGE 124 FOR SINGLE CHANNEL SERVICE KIT # 52-940-0765-90
PCB ASSEMBLY NSP T765 Left Amp Board Assembly NSP
IC & REGULATORS
U5805 01-004-0049-00 I.C Volt Reg 12V 1A TO-220 NJM7812
U5804 01-004-0054-90 IC REG 1A TO-220(T) LM317T
U5803 01-020-0026-90 IC LM35DT TEMP SENSOR TO-220
RESISTORS
R5528 R5530 R5628 R5630 R5728 02-005-0063-00 RES WW 0.22 OHM 5% 5W AXIAL
R5730
R5536 R5636 R5736 02-010-0014-00 RES MO 10 OHM 5% 2W AXIAL
CAPACITORS
C5806 03-002-0066-00 E CAP 1000uF/25V±20% 105*C
10x20mm
C5518 C5618 C5718 03-004-0031-00 MPF CAP 104J/63V 5% Mini Box
TRANSISTORS
Q5518 Q5618 Q5718 05-001-0100-90 TRANSISTOR PW DARLINGTON PNP
10A/150V TO-3PB 2SB1560
Q5517 Q5617 Q5717 05-001-0101-90 TRANSISTOR PW DARLINGTON NPN
10A/150V TO-3PB 2SD2390
VARIABLE RESISTORS
R5521 R5621 R5721 06-004-0016-90 VR SEMI-FIX RES CF 1K OHM B 30%
6mm
COILS
L5501 L5601 L5701 07-002-0136-90 AIR COIL 0.2uH +/-10% 1 X 9 X 13.5
TURNS
RELAYS
M5801-5804 07-005-0043-90 RELAY POWER DC12V 10A/250V 1P1T
TV5 UL/SEMKO/CQC JZC-36F-012-HSL
THERMISTOR
M5805 M5808 20-004-0039-00 THERMISTOR PTC 100 OHM PTFM04B
H471Q2N34B0
SMD ICS
U5501 01-012-0065-00 IC LOGIC 8-STAGE SHIFT-AND-STORE
BUS REGISTER SMD SO16 HEF4094BT
U5802 01-014-0043-00 SMD IC AS358MTR-E1 SOIC-8 OPERA
TIONAL AMPLIFIER BCD
