74
C5604 C5704 C5504 03-009-0144-00 CAP ELEC SMD 470uF 16V +/-20%
10X10.5
C5609 C5611 C5709 C5711 03-009-0145-00 CAP ELEC SMD 47uF 100V +/-20%
C5509 C5511 C5810 10X10
C5816 03-009-0153-00 SMD E CAP 1uF/50V ±20% B CASE 4 X
5.4
C5801 C5808 C5819 03-009-0211-00 SMD E CAP 220uF/16V ±20% 6.3X7.7
SMD DIODES
D5502 D5503 D5602 D5603 D5702 04-006-0019-00 SMD Diode RECT 1A/400V DO-214AC
D5703 D5809-D5812 D5816 GS1G M4 GS1G
D5504-5510 D5604-5610 D5704-5710 04-006-0021-90 SMD Diode LL4148 SOD80
D5801-5802 D5804-5805 D5808 D5813
D5814 D5815
D5803 D5807 04-007-0031-00 DIODE ZENER SMD 6.2V 500mW 5%
SOD123 MMSZ5234B
D5501 D5601 D5701 04-007-0035-90 DIODE ZENER SMD 15V 500mW 5%
SOD123 MMSZ5245B
SMD TRANSISTORS
Q5501-5505 Q5511-5512 Q5519 05-004-0018-00 SMD Transistor MMBT5551LT1 NPNCAP
Q5601-5605 Q5611-5612 Q5619 ELEC SMD SOT-23
Q5701-5705 Q5711-5712 Q5719
Q5805-5806 Q5810
Q5508 Q5608 Q5708 Q5807 Q5808 05-004-0019-00 SMD Transistor MMBT5401LT1G PN
Q5811 PCAP ELEC SMD SOT-23
Q5710 Q5610 Q5510 05-004-0030-90 SMD XTR 2SD1918 NPN POWER
160V/1.5A 80MHz HFE 120-390
Q5506 Q5507 Q5509 Q5606 Q5607 05-004-0031-90 SMD XTR 2SB1275 PNP POWER
Q5609 Q5706 Q5707 Q5709 160V/1.5A 50MHz HFE 82-180
Q5812 05-004-0032-90 SMD XTR N-CH 2SK771-4 40V 20mA
IDSS=2.5 - 6 Ma
Q5809 05-004-0035-90 TRANSISTOR SS NPN HFE30 250MHz
SPT DTC114EKAT146
Q5801-5804 05-004-0036-90 TRANSISTOR SS NPN HFE20 250MHz
DTC123EKAT146
VOLUME BOARD
PCB ASSEMBLY 50-914-0765-90 T765/T775/T785 VOLUME ASSY
IC
U6009 01-025-0002-90 IC LC78211 ANALOG FUNCTION
SWITCH 30 PIN DIP
INDUCTORS
L6010 L6011 07-002-0144-90 IND CHOKE 180uH +/-10% AXIAL EC24-
181K EASE HOUSE
RELAYS
M6004 07-005-0049-90 RELAY DC12V 0.5A/125V 2P2T KH1-12
VDC MINIATURE PCB MOUNT
RCA JACKS
M6001-M6003 15-003-0047-90 RCA JACK 6 R-R-R/W-W-W PCB
MOUNT GOLD W/O COVER
SMD ICS
U6003 01-012-0065-00 IC LOGIC 8-STAGE SHIFT-AND-STORE
BUS REGISTER SMD SO16 HEF4094BT
U6004-6007 U6018 01-014-0041-00 IC AUDIO LOW NOISE OP-AMP SMD
NJM5532M
