NAD T 775 - Page 79

77
TACT SWITCH
S1001 11-007-0061-90 SW TACT 1P1T 50mA/12V VER H=5mm
LUG FUNG
RCA JACKS
M1005 M1006 M1007 M1008 15-003-0034-90 RCA JACK 1 ORANGE PCB MOUNT
GOLD W/SHIELD
SMD ICS
U1020 01-004-0056-90 IC VOLT REG. LOW DROPOUT 3.3V 1A
SOT-223 LM1117S-3.3
U1034 01-004-0061-90 IC VOLT REG LOW DROPOUT 5.0V 1A
SOT-223 LM1117S-5.0
U1001 01-010-0024-90 IC D708E001BRFP266 FLOATING-
POINT DSP SMD 144 PINS S-PQFP-144
U1004 01-011-0032-90 IC FLASH MEMORY SMD 8M 3.3V
SST39VF800A-70-4C-EK TSOP
U1003 01-011-0033-90 IC SDRAM 1M X 4 X 16BIT 133MHz SMD
54PIN TSOP(II) K4S641632K-T(U)C/L75
U1005*AH U1005-1006*C CT 01-012-0061-00 IC LOGIC 8-CHANNEL MULTIPLEXER
SOP 74HC251D
U1007 U1008 01-012-0065-00 IC LOGIC 8-STAGE SHIFT-AND-STORE
BUS REGISTER SMD SO16 HEF4094BT
U1018-1019 01-012-0066-00 IC LOGIC HEX INVERTER SMD SOP
74HCU04D
U1010 U1022 01-012-0068-90 IC LOGIC OCTAL BUS TRANSCEIVER
WITH 3-STATE OUTPUTS 20PIN TSSOP
SN74LVC245APWER
U1011 01-012-0074-90 IC PWM CONTROL IC SOP8 TL5001CD
U1009 01-012-0083-90 IC LOGIC OCTAL BUS TRANSCEIVERS
WITH 3-STATE OUTPUTS SMD SN74H
CT245PWR
U1033 U1035 U1036 01-012-0088-90 IC LOGIC QUAD 2-INPUT MULTIPLEX
ER WITH 3-STATE OUTPUTS SN74LV
C257AD
U1023 U1027-1031 01-014-0041-00 IC AUDIO LOW NOISE OP-AMP SMD
NJM5532M
U1017 01-020-0022-90 IC AUDIO STEREO ADC PCM1802
SOP20
U1021 01-020-0023-90 IC SUPPLY-VOLTAGE SUPERVISORY
IC SOP6 TPS3103E12DBVR
U1002 01-020-0024-90 IC 192KHz DIGITAL AUDIO INTERFACE
RECEIVER 28PIN SOIC CS8416 -CS
U1032*AH 01-020-0030-90 IC XMDT IC BU9450KV VQFP48C
U1012-1016 01-027-0011-90 IC PCM1791A 24-BIT 192kHz AUDIO
STEREO DAC SMD 28 PIN SSOP
SMD RESISTORS
R1006 R1013 R1020 R1032 R1231 02-007-0042-00 RES SMD 1K OHM 0603 5%
R1242-1243*AH
R1022-1024 R1034 02-007-0134-00 RES SMD 4.7 OHM 0805 5%
R1316-1317 R1035*C CT 02-007-0139-00 RES SMD 4.7K OHM 0603 5%
R1005 R1012 R1019 R1031 R1061 02-007-0140-00 RES SMD 47K OHM 0603 5%
R1071-1072
R1062 R1069 R1240 R1244-1245*AH 02-007-0141-00 RES SMD 100 OHM 0603 5%
R1028 02-007-0146-00 RES SMD 47 OHM 0603 5%
R1078-1079 R1082-1083 R1086-1087 02-007-0151-00 RES SMD 10 OHM 0603 5%
R1090-1091 R1167-1168 R1226 R1190
R1199 R1208
R1050 02-007-0153-00 RES SMD 20K OHM 0603 5%
