9
WIRING DIAGRAM PARTS LIST
Item Database Part Number Description Remark
1 17-012-2965-90 CABLE ASSY 4 WAYS #26 2.5P L=400mm PSU
BD-J8002A
2 17-012-3943-90 CABLE ASSY 1 WAY #16 UL1672 BLUE PSU
L=140mm FASTON 4.8mm BD-J8011
3 17-012-3944-90 CABLE ASSY 1 WAY #16 UL1672 BROWN PSU
L=140mm FASTON 4.8mm BD-J8012
4 17-012-3940-90 CABLE ASSY 3 WAYS #26 2.5P UL2854 VOL
L=110 BD-J6004A/B
5 17-012-3938-90 CABLE ASSY 1 WAY #18 UL1007 L=320MM DSP
W/ HEADER BD-J1002A
6 17-012-3378-90 CABLE ASSY 20 WAYS #28 UL2651 L=240mm KEYBOARD
PCB MOUNT -J2002B
7 17-012-3173-90 CABLE ASSY 14 WAYS #26 2.5P UL1533 PRE-OUT
L=100 BD-J5404B
8 17-012-3176-90 CABLE ASSY 3 WAYS #18 3.96P UL1007 SEC
L=80 BD-J5804B
9 17-012-3208-90 CABLE ASSY 4 WAYS #18 3.96p UL1007 SEC BD-
L=150 J8101A,J8102A
10 17-012-3209-90 CABLE ASSY 4 WAYS #18 3.96P UL1007 SEC BD-
L=170 J8103A+J8104A
11 17-012-3174-90 CABLE ASSY 5 WAYS #18 3.96P UL1007 SPK BD-
L=300mm (W/R/B/V/O) J5403B1-B5
12 17-012-3947-90 CABLE ASSY 4 WAYS #18 3.96P UL1007 L=260 SPK BD-
(W/R/Y/BL) J5802B1-B4
13 17-012-3329-90 CABLE ASSY 3 WAYS #18 UL1007 3.96P L=420 SPK BD-
J8106B1-B3
14 17-012-3330-90 CABLE ASSY 4 WAYS #18 UL1007 3.96P L=440 SPK BD-
J8105B1-B4
15 17-012-3171-90 CABLE ASSY 6 WAYS #26 2.5P UL1533 L=200 V6 VD-
J2006B
16 17-012-3404-90 CABLE ASSY 6 WAYS #26 2.5P UL1007 L=150 V6 BD-
J2005B
17 17-012-3939-90 CABLE ASSY 3 WAYS #26 2.5P UL2468 L=180 ISC BD-
J5803B,J5810B
18 17-012-3930-90 CABLE ASSY 4 WAYS #26 2.5P UL1533 L=160 V6 BD-
J2008A
19 17-012-3936-90 CABLE ASSY 3 WAYS #26 2.5P UL2854 L=310 CONN#1-
J9006A
20 17-012-3937-90 CABLE ASSY 5 WAYS #26 2.5P UL2854/1533 CONN#1-
L=230/320 J9004A/J9005A
21 17-012-3938-90 CABLE ASSY 1 WAY #18 UL1007 L=320 CONN#1-
W/ HEADER JP9001A
22 17-012-3941-90 CABLE ASSY 3 WAYS #26 2.5P UL2854 L=130 CONN#1-
J9008A/B
23 17-012-3457-90 CABLE ASSY 8 WAYS #26 UL1007 2.5P L=120 CONN#2-
J8202B
24 17-012-3458-90 CABLE ASSY 10 WAYS #26 UL1007 2.5P L=80 CONN#2-
J8201B
25 17-010-0122-90 FFC CABLE 17 PINS P1.25 L=360 15 & 16 TUNER-
PINS VOID J5404B
26 17-012-2874-90 CABLE ASSY 1 WAY #16 UL1672 BLUE J8015,J8017
L=100mm
27 17-012-2875-90 CABLE ASSY 1 WAY #16 UL 1015 CHASSIS GND,
GREEN/YELLOW L=100
AC OUTLET GND
28 17-012-3166-90 CABLE ASSY 20 WAYS #28 UL2651 L=100mm J2001C,J7001C
29 17-012-3298-90 CABLE ASSY 3 WAYS #18 UL1007 L=420mm J5402A/B
30 17-012-3346-90 CABLE ASSY 26 WAYS #28 UL2651 L=330mm J2301C
31 17-012-3942-90 CABLE ASSY 26 WAYS #28 UL2651 L=230mm J2007C
32 17-012-3948-90 CABLE ASSY 1 WAY #16 UL1672 BROWN L=100 J8013,J8016
33 17-012-3963-90 CABLE ASSY 1 WAY #18 UL1007 L=200 W/ HEADER TUNER-
J6102A
34 17-012-3965-90 CABLE ASSY 3 WAYS #26 2.5P UL2547 L=500 TUNER-
J9501A
35 17-012-2924-90 CABLE ASSY 1 WAY AWG18 UL1015 BLACK
MAIN-JP7006B-GND,
L=260mm W/RING TERMINAL SEC BD-J8153A-GND
